The «SCORPION» portable EW backpack is a mobile wearable electronic warfare system (category: EW Backpacks / Portable EW Backpacks), designed for individual protection of soldiers against FPV drones and kamikaze drones. The basic configuration operates in 7 channels (a combination of 4×50 W + 1× LoRa module 100 W) with a total power of 300 W. All key elements have IP68 protection, making the system completely resistant to dust and moisture. The kit includes a durable carrying backpack, a 30,000 mAh battery, a 10 A charger, and a protective head buff against radiation as a gift. A circulator protects the modules from failure if antennas detach.

Key Features

• Name: «SCORPION» Portable EW Backpack
• Product type: EW Backpacks (portable wearable version)
• Number of channels (basic): 7 channels (4×50 W + 1× LoRa module 100 W for 3 bands)
• Channel power: 50 W (standard module) / 100 W (LoRa module for 3 bands)
• Total power: 300 W (4×50 + 100 W)
• Effective operating range: 50–400 m
• Cooling: active + passive
• Antennas: spring omnidirectional 32×60, gain 6 dBi (IP68 protection)
• Module protection: circulator against failure if antennas detach
• Housing and electronics protection: IP68
• Weight of assembled backpack: ~6.5 kg + battery 3 kg

Available Frequency Bands for 50 W Modules (selectable)

• 200–300 MHz
• 300–400 MHz
• 400–500 MHz
• 500–610 MHz
• 610–720 MHz
• 720–840 MHz
• 840–950 MHz
• 950–1050 MHz
• 1050–1200 MHz
• 1200–1350 MHz
• 2.4 GHz (Mavic) — optional
• 5.2 GHz (Autel) — optional
• 5.8 GHz (video) — optional

LoRa Modules 100 W (for 3 bands from one antenna)

LoRa modules have increased noise density and cover 3 bands simultaneously from one module and one antenna. 3 configurations are available:

• 100–400 MHz (60 W): 100–200 / 200–300 / 300–400 MHz
• 420–720 MHz (100 W): 420–500 / 500–610 / 610–720 MHz
• 720–1020 MHz (100 W): 720–840 / 840–950 / 950–1020 MHz

According to the manufacturer's documentation, 7 channels are implemented by a combination of 4×50 W + 1× LoRa module (100 W) — this means 4 standard channels plus 3 bands from one LoRa module. In a setup with two devices, an 11-channel EW system from 300 to 1350 MHz can be implemented, with the addition of 2.4 and 5.8 GHz. By default, all channels are activated simultaneously — if desired, relays can be added to control individual frequencies.

Autonomy

• Battery: 30,000 mAh (included)
• Operating time with 1 battery: ~1 hour
• Operating time with 2 batteries: ~2 hours
• Charger: 10 A (included)
• Battery charge sensor: built-in

Advantages

• Full IP68 protection: fans, converter, modules, relays — all components are protected from dust and water, ensuring full operation in rain and snow.
• Built-in circulator: protects the module from failure if antennas detach (unlike unprotected Chinese counterparts).
• Powerful spring antennas: 32×60 at 6 dBi, high radiation efficiency.
• Maximum frequency coverage: 7 channels — one of the widest configurations for portable EW; thanks to the LoRa module, it covers 3 additional bands simultaneously.
• Mobility: portable in a durable backpack — ready for individual use by a soldier.
• Protective buff as a gift: protects the operator's head from EW radiation during wear.
• Dual cooling: active + passive for stable operation during long missions.
• Convenient charge control: built-in battery charge sensor.
• Relay option: control individual frequencies instead of simultaneous activation of all channels.

Package Contents

• «SCORPION» 7-channel EW device — 1 pc.
• Durable carrying backpack
• Spring omnidirectional antennas 32×60 — 5 pcs. (4 for 50 W modules + 1 for LoRa module)
• 30,000 mAh battery
• 10 A charger
• ???? Protective head buff against radiation — as a gift
• Battery charge sensor (built-in)

Additional Options

Technical Specifications

The «SCORPION» 7-channel EW backpack is the most powerful portable solution with the widest frequency coverage for individual protection of soldiers against FPV drones and kamikaze drones. The 4×50 W + 100 W LoRa module configuration ensures simultaneous suppression in the most critical UAV control bands. The combination of IP68 protection, circulator, powerful 32×60 6 dBi spring antennas, active and passive cooling, and compact weight (~6.5 kg + battery) makes the system ideal for foot patrols, patrolling, and assault missions. As a gift — a protective head buff against radiation, which additionally protects the operator during prolonged wear of the active device.
