Army Tent USB-56
The USB-56 tent from manufacturer FCT DESIGN is a spacious and reliable field tent, designed based on the 1956 model. The model was named after its design year and is deservedly considered one of the most massive and versatile army tents. Its design, featuring a four-slope roof, two entrances with vestibules, and numerous windows, makes it suitable for accommodating personnel, medical stations, and headquarters in field conditions.
The USB-56 is designed for use in various seasons: in cold weather, provisions are made for installing stoves and insulating the hanging walls with flannel, while in the warm season, the insulation can be removed. Thanks to its well-thought-out configuration and durable materials, the tent withstands intensive use in field conditions.
Typical Applications
- housing medical and sanitary points in field conditions;
- accommodating personnel during exercises;
- utility needs and catering;
- locating command headquarters;
- universal field needs: from shelter to equipment storage.
Main Technical Specifications
USB-56 type tent 6x9. Length: 9 m. Width: 6 m. Side wall height: 1.75 m. Ridge height: 3.55 m. Floor area: 54 m². Total kit weight: 220 kg. Assembly time: 1.5 hours/3 persons. Capacity: 20 to 80 people depending on bed type and equipment arrangement.
Kit Contents (list of parts and weight)
| No. | Part Name | Quantity | Unit Weight kg | Total Kit Weight kg |
|---|---|---|---|---|
| 1 | Outer tent | 1 | 125.80 | 125.80 |
| 2 | Inner tent | 1 | 33.50 | 33.50 |
| 3 | Hanging heating walls | 2 | 18.80 | 37.60 |
| 4 | Side guy ropes 2.8 m with handle | 30 | 0.55 | 16.50 |
| 5 | Guy rope tensioner | 2 | 0.40 | 0.80 |
| 6 | Subframes | 12 | 0.65 | 7.80 |
| 7 | Window frames | 12 | 2.00 | 24.00 |
| 8 | Iron sheet for chimney | 2 | 1.15 | 2.30 |
| 9 | Corner stakes 50x50x4 mm, 0.6 m long | 30 | 2.40 | 72.00 |
| 10 | Middle pole, 2 parts | 2 | 14.20 | 28.40 |
| 11 | Wooden side poles 1.89 m | 22 | 1.98 | 43.56 |
| 12 | Wooden vestibule poles 1.79 m | 4 | 1.94 | 7.76 |
| 13 | Ridge pole, 2 parts | 1 | 14.24 | 14.24 |
| 14 | Tarpaulin for fabric parts | 2 | 4.70 | 9.40 |
| 15 | Rigging bag | 1 | 0.34 | 0.34 |
| 16 | Cassette for subframes, frames, and chimney sheets | 2 | 6.50 | 13.00 |
| 17 | Wooden boxes for metal stakes | 3 | 4.10 | 12.30 |
| 18 | Sledgehammer 5 kg with handle | 1 | 6.00 | 6.00 |
The USB-56 tent is a proven solution for field tasks, combining large dimensions, heating capability, and convenient internal space organization. If you need spacious temporary shelter for a medical station, a dormitory at a training ground, or staff workstations, this model meets such requirements. Manufacturer: FCT DESIGN.
