iFlight XING2 2604 1350KV / 1650KV Motor — Overview and Key Advantages

Name: iFlight XING2 2604 1350KV / 1650KV Motor
Manufacturer: iFlight
Category: Drones & Quadcopters > Drone Accessories

This iFlight XING2 2604 brushless motor combines reliability, high efficiency, and a compact design. The model is available in two KV (revolutions per volt) options: 1350KV and 1650KV, allowing you to choose the optimal variant for a specific project — from a stable platform for aerial photo/video shooting to a nimble racing quadcopter.

Detailed Specifications

• 1. Motor Type: Brushless motor — high efficiency, durability, and reliability.
• 2. KV (Revolutions per Volt): 1350KV — moderate KV for greater thrust and stability when lifting heavy cameras or equipment; 1650KV — higher KV for quick response, better maneuverability, and freestyle maneuvers.
• 3. Stator Size: 26 mm stator diameter (2604 — 26 mm / 04 mm height).
• 4. Weight: approximately 34 grams per motor, making it lightweight for various multi-copter platforms.
• 5. Casing Material: The casing is made of high-quality aluminum, which contributes to efficient heat dissipation and extends the motor's service life.
• 6. Number of Stator Poles: 12 poles for increased precision and rotational stability.
• 7. Operating Voltage: recommended 4S–6S (14.8V – 22.2V) configurations to ensure high performance with various batteries.
• 8. Mounting Thread: standard M3 thread for propeller attachment.
• 9. Application: suitable for many types of multi-rotor drones: aerial photo and video projects, heavier platforms with cameras, racing quadcopters, and freestyle. The choice between 1350KV and 1650KV depends on the priority — thrust and stability or speed and maneuverability.

The iFlight XING2 2604 motor is designed for users who need a reliable drive with a good balance between weight, heat dissipation, and performance. The aluminum casing and 12-pole stator ensure quality operation under load, while the compact dimensions and low weight make the motor versatile for various frames and configurations. If you need a motor for a heavier payload, choose the 1350KV option; if speed and aggressive handling are a priority, the 1650KV option will be a better choice.

The model is well compatible with modern ESCs and propellers that support M3 thread mounting, and it shows excellent performance when powered by 4S to 6S batteries. This makes the iFlight XING2 2604 a flexible solution for both amateur and professional drone projects.
