Information

• Product Name

  UltraGear

  Year

  Y24

DISPLAY

• Size [inch]

  26.5

  Size [cm]

  67.3

• Resolution

  2560 x 1440

  Panel Type

  OLED

• Aspect Ratio

  16:9

  Pixel Pitch [mm]

  0.2292 x 0.2292 mm

• PPI (Pixel Per Inch)

  111

  Brightness (Min.) [cd/m²]

  250 cd/m²

• Brightness (Typ.) [cd/m²]

  275 cd/m²

  Color Gamut (Min.)

  DCI-P3 90% (CIE1976)

• Color Gamut (Typ.)

  DCI-P3 98.5% (CIE1976)

  Color Depth (Number of Colors)

  1.07B

• Contrast Ratio (Min.)

  1200000:1

  Contrast Ratio (Typ.)

  1500000:1

• Response Time

  0.03ms (GtG)

  Refresh Rate (Max.) [Hz]

  240

• Viewing Angle (CR≥10)

  178º(R/L), 178º(U/D)

FEATURES

• HDR 10

  YES

  VESA DisplayHDR™

  DisplayHDR™ TRUE BLACK 400

• HDR Effect

  YES

  Factory Color Calibration

  YES

• HW Calibration

  HW Calibration Ready

  Reader Mode

  YES

• Color Weakness

  YES

  NVIDIA G-Sync™

  G-SYNC Compatible

• AMD FreeSync™

  FreeSync Premium Pro

  VRR

  YES

• VESA AdaptiveSync

  YES

  Black Stabilizer

  YES

• Dynamic Action Sync

  YES

  Crosshair

  YES

• FPS Counter

  YES

  User Defined Key

  YES

• Auto Input Switch

  YES

  RGB LED Lighting

  Hexagon Lighting

• Smart Energy Saving

  YES

  Live Color Low Blue Light

  YES

SOFTWARE

• LG Calibration Studio (True Color Pro)

  YES

  OnScreen Control (LG Screen Manager)

  YES

CONNECTIVITY

• HDMI

  YES (2ea)

  HDMI Version

  FRL Supported as HDMI 2.1 Compatible

• HDMI (HDCP Version)

  2.3

  DisplayPort

  YES (1ea)

• DP Version

  1.4 (DSC)

  DP (HDCP Version)

  2.3

• USB Out Port

  YES (1ea/ver3.0)

  USB In Port

  YES (2ea/ver3.0)

• Headphone Out

  4-pole (Sound+Mic)

SOUND

• DTS Headphone: X

  YES

POWER

• Type

  External Power (Adapter)

  AC Input

  100~240V (50/60Hz)

• Power Consumption (On Mode)

  37.7W

  Power Consumption (Operating Mode) (ErP)

  25W

• Power Consumption (Operating Mode) (KR)

  37.7W

  Power Consumption (Sleep Mode)

  Less than 0.5W

• Power Consumption (DC Off)

  Less than 0.3W

MECHANICAL SPECIFICATIONS

• Display Position Adjustments

  Tilt/Height/Pivot/Swivel

  Wall Mount [mm]

  100 x 100 mm

DIMENSIONS/WEIGHT

• Dimensions with Stand (W x H x D) [mm]

  604.4 x 574.4 x 258 mm (UP) / 604.4 x 464.4 x 258 mm (DOWN)

  Dimensions without Stand (W x H x D) [mm]

  604.4 x 350.6 x 45.3 mm

• Dimensions in Shipping (W x H x D) [mm]

  808 x 181 x 532 mm

  Weight with Stand [kg]

  7.35 kg

• Weight without Stand [kg]

  5.05 kg

  Weight in Shipping [kg]

  11.0 kg

ACCESSORIES

• HDMI

  YES (ver 2.1)

  Display Port

  YES

• USB A to B

  YES

  Remote Controller

  YES
