Built-in energy-efficient circulation pump Taso ES2 C 15-70-130
Frost and overheat protection
Heat output: 44.55 kW
Total max. consumption: 45.2 kW
Efficiency: 99.7%
Coil arrangement: 2x15 kW + 2x7.5 kW
Number of stages: 4(3)
Number of contactors: 4
Output power adjustment: 22.5 kW - 30 kW - 37 kW - 45 kW
Current: 67 A
Automatic circuit breaker for boiler circuit: 80 A
Min. cross-sectional area of power cables: 5(4)x16 mm2
Fuse type in boiler: 160 A
Voltage: 3x400/230 V
Enclosure protection rating: IP40
Terminals for thermostat on/off: 230 V
Max. operating pressure: 2.5 bar
Min. operating pressure: 0.8 bar
Water volume: 29.5 L
Max. water heating temperature: 90°C
Expansion tank absent
Safety valve 1/2": 2.5 bar
Inlet pipe diameter (external thread): G1"
Outlet pipe diameter (external thread): G1"
Boiler weight without water: 53 kg
Device dimensions: 615x870x335 mm
Country of manufacture: Czech Republic
