Jinma 260 E Mini Tractors
The Jinma 260 E mini tractor is a reliable representative of the Tractors > Mini Tractors category from the Jinma brand. It is a rear-wheel-drive machine with a nominal power of 24 hp (17.6 kW), equipped with a three-cylinder 4-stroke liquid-cooled (water-cooled) diesel engine with a displacement of 1,532 cm3. The model is equipped with power steering for easier control and has compact dimensions: one description indicates dimensions of 3085x1440x1930 mm (with muffler), while the technical table lists overall dimensions (LxWxH) of 3080/1280/1930 mm.
Purpose, Operation, and Advantages
The Jinma 260 E is widely used in farming and agriculture, optimal for land plots up to 10 hectares. Thanks to the tractor's high maneuverability, it works effectively in hard-to-reach areas and is compatible with various attachments. Drum-type brakes allow individual locking of the right and left wheels, which increases maneuverability when working on slopes or during skidding.
The model is suitable for plowing, mowing grass, baling straw, pumping water with a pump, transporting goods, and other agricultural operations. The maximum permissible transport load capacity is up to 420 kg, while the maximum lifting capacity of the hitch mechanism is 400 kg. In winter, the Jinma 260 E is effectively used for snow removal. Optionally, a roof canopy can be installed to protect the driver from precipitation, and the shock-absorbing seat enhances comfort during long hours of work.
The gearbox is mechanical, non-synchronized (4 forward + 1 reverse) x 2, ensuring a simple and reliable design with a long service life. Other key advantages include: rear differential lock, dry single-disc clutch, 540 rpm PTO, economical fuel consumption (nominal consumption ≤275 g/kWh), and compact dimensions for working on small plots.
Recommended alternative models:
- Jinma 404
- Shifeng 354
- Dongfeng
- Xingtai
- Foton
- Zoomlion
- DTZ 5244
- Bulat 454
- Bulat 250
- Bulat 254
- Belarus 320.4
- Shifeng 350 L
- DW 244
- DTZ 5404K
- Solis 26 Tractor
- Solis 50
- Shifeng SF-244
Specifications:
| Engine power, hp (kW) | 24 hp (17.6) |
| Wheel formula | 4x2 |
| Engine type | 4-stroke water-cooled diesel engine |
| Engine displacement, cm3 | 1,532 |
| Nominal fuel consumption g / kWh | ≤275 |
| Nominal engine crankshaft speed rpm | 2,350 |
| Nominal traction force kN | 7.7 |
| Gearbox (transmission) | non-synchronized, mechanical (4 forward + 1 reverse) x 2 |
| Rear differential lock | Yes |
| Clutch | Dry, single-disc |
| Power steering | Yes |
| Braking mechanism | drum type |
| Power take-off (PTO) speed rpm | 540 |
| Maximum lifting capacity of hitch mechanism, kg | 400.0 |
| Wheelbase, mm | 1595 |
| Front wheel track, mm | 1070~1270 |
| Rear wheel track, mm | 1040~1200 |
| Front tire size | 5.00-15 |
| Rear tire size | 9.50-24 |
| Theoretical forward speed, km / h | 26.4 |
| Theoretical reverse speed, km / h | 11.0 |
| Fuel tank volume L | 18 |
| Engine crankcase volume, L | 4 |
| Gearbox and rear axle crankcase volume, L | 14.0 |
| Lift housing volume, L | 9 |
| Engine cooling system volume, L | 12 |
| Overall dimensions (LxWxH), mm | 3080/1280/1930 |
| Structural weight, kg | 1,040 |
Brand: Jinma. Category: Tractors > Mini Tractors. This model combines ease of operation and maintenance with a wide range of capabilities for agricultural and municipal work.
