Mini Tractor Zoomlion RF 354 B
Zoomlion RF 354 B is a reliable all-wheel-drive mini tractor from the Zoomlion brand, designed for intensive use on farms, private households, and for commercial tasks. This model combines robust mechanics, modern design, and convenient solutions for working in any conditions. Stylish optics with wide light distribution from the main headlights ensure comfortable operation in the evening and at night, while the hood with an opening for fuel tank access simplifies maintenance.
Engine and Starting System: The mini tractor is equipped with a 4-cylinder water-cooled diesel engine with a displacement of 2156 cm3 and a power of 35 hp (25.7 kW). For reliable starting in low temperatures, a glow plug is provided, and a powerful 90 Ah battery guarantees electric start. A protective metal mesh is installed in front of the radiator, and the hood easily lifts with a shock absorber for access to components.
Control and Comfort: The steering wheel is equipped with power steering with a double-acting hydraulic cylinder; the tractor has two hydraulic pumps for stable operation of the hydraulic system. The instrument panel includes an hour meter, oil and air pressure gauges, water temperature, fuel level, and an ammeter. For safety, separate brake pedals with manual locking are provided. Operator comfort is enhanced by a soft seat adjustable for weight and height; throttle control is available via both a hand lever and a pedal. Spherical rearview mirrors and a rear work light improve visibility and safety during maneuvering.
Chassis and Tracks: The model features a 4x4 wheel formula, wide fenders on the wheels, and detachable rear wheel discs, allowing the track to be adjusted over a wide range for working with various attachments. Front tires are 6.5-16, rear are 11.2-24. The wheelbase is 1818 mm, front wheel track is 1100 mm, rear wheel track is 960~1460 mm.
Attachments and Connectors: Included is a 2-speed power take-off (PTO) shaft with speeds of 540/1000 rpm, an additional hydraulic distributor with two hydraulic outlets, a pneumatic outlet, a trailer socket, a powerful hitch, and a towing device. This makes the tractor versatile for working with a wide range of mounted and trailed equipment.
Technical Specifications
| Engine power, hp (kW) | 35 hp (25.7) |
| Wheel formula | 4x4 |
| Engine type | 4-cylinder water-cooled diesel engine |
| Engine start | electric starter with safe start |
| Engine displacement, cm3 | 2156 |
| Nominal fuel consumption g / kW * h | ≤244 |
| Nominal traction force kN | 7.7 |
| Gearbox (КПП) | (4+1)x2 mechanical |
| Rear differential lock | Yes |
| Clutch | Dry, twin-disc |
| Power steering | Yes |
| Power take-off (PTO) shaft speed rpm | 540/1000 |
| Wheelbase, mm | 1818 |
| Front wheel track, mm | 1100 |
| Rear wheel track, mm | 960~1460 |
| Front tire size | 6.5-16 |
| Rear tire size | 11.2-24 |
| Theoretical forward speed, km / h | 1.8 - 27.5 |
| Theoretical reverse speed, km / h | 3.23 - 7.7 |
| Fuel tank capacity L | 30 |
| Overall dimensions (LxWxH), mm | 3312/1524/2556 |
| Structural weight, kg | 1500 |
The Zoomlion RF 354 B mini tractor is a versatile solution for soil cultivation, transportation, garden work, and municipal services. It combines robust construction, operator comfort, and multifunctionality thanks to a powerful hydraulic system, extended attachment connection capabilities, and two PTO speeds. You can order the tractor at a favorable price with free delivery throughout Ukraine in our store.
