KENTAVR 244 SX Mini Tractor — Overview and Key Specifications
KENTAVR 244 SX is a reliable and compact mini tractor from the manufacturer KENTAVR, designed for work on small farms, private households, and garden plots. This model belongs to the category: Tractors > Mini Tractors and combines a powerful diesel engine with 4x4 all-wheel drive, ensuring excellent cross-country capability and versatility of use.
Purpose and Advantages
The KENTAVR 244 SX is ideal for soil cultivation, preparatory agricultural work, transportation, and the use of trailers and attachments. Thanks to its robust construction, liquid cooling system, and power steering, operation becomes comfortable and safe. The model is equipped with a rear PTO with two speeds (540/1000 rpm), rear differential lock, and mechanical steering.
Technical Data
Below is the complete technical information for the KENTAVR 244 SX model. All parameters from the original description are preserved:
| Engine power, hp (kW) | 24 (17.65) |
| Wheel formula | 4x4 |
| Engine type | diesel, 4-stroke, direct injection, naturally aspirated |
| Number and arrangement of cylinders | 3, vertical |
| Engine start system | electric starter |
| Cooling system | liquid, closed, with forced circulation of coolant |
| Cooling fan drive | V-belt drive |
| Engine displacement, cm3 | 1530 |
| Cylinder bore / piston stroke, mm | 85 / 90 |
| Nominal engine fuel consumption, g/kW*h | ≤275 |
| Nominal engine crankshaft speed, rpm | 2300 |
| Nominal traction force, kN | 7.2 |
| Engine oil type | mineral or semi-synthetic for diesel engines |
| Nominal engine oil consumption, g/kW*h | 2.31 |
| Transmission (КП) | (4+1)x2 |
| Transmission and rear axle oil type | Silver SAE 85W-90; Gold SAE 80W-90; Platinum SAE 75W-90 (transmission) |
| Front axle oil type | Silver SAE 85W-90; Gold SAE 80W-90; Platinum SAE 75W-90 (transmission) |
| Rear differential lock | + |
| Clutch | dry, single-disc, constantly closed type |
| Final drive | direct |
| Steering | mechanical |
| Brakes | on rear wheels, brake drums |
| Power take-off (PTO) | rear, splined |
| Hydraulic system pump type | gear pump |
| Power take-off (PTO) speed, rpm | 540 / 1000 |
| Maximum lifting capacity of the hitch mechanism, kg | 420 |
| Minimum ground clearance, mm | 315 |
| Wheelbase, mm | 1660 |
| Wheel track, mm | front 1220, 1440, rear 1120, 1360, 1400 |
| Tire size | front 7.50-16 rear 11.20-24 |
| Minimum turning radius, m | without brakes 3.5 with brakes 3.2 |
| Travel speed, km/h | forward 0.37-30.64 reverse 0.49-12.23 |
| Fuel tank volume, L | 18.5 |
| Engine crankcase volume, L | 4.5 |
| Transmission and rear axle crankcase volume, L | 14.0 |
| Front axle crankcase volume, L | 3.0 |
| Engine cooling system volume, L | 6.0 |
| Number of hydraulic outputs | 2 |
| Trailer connector (socket) | + |
| Power steering | + |
| Overall dimensions (L x W x H), mm | 3400x1490x2050 |
| Curb weight, kg | 1370 |
This model combines compact dimensions with sufficient power for a wide range of agricultural and household tasks. The presence of two PTO speed ranges allows for efficient use of various attachments, while the differential lock and power steering ensure maneuverability in difficult conditions and on rough terrain. It is recommended to use the specified transmission oils (Silver, Gold, Platinum) to extend the service life of the gearbox and axles.
If you need a compact, functional mini tractor with all-wheel drive and a high-quality basic configuration, the KENTAVR 244 SX will be an optimal choice for private households and farmers who value reliability and ease of maintenance.
