Mini Tractor Dongfeng DF 404D

Mini Tractor Dongfeng DF 404D is a reliable and maneuverable small-class unit designed for farms, utility work, and a wide range of agricultural operations. Brand: DongFeng. Type: Tractors > Mini Tractors. This mini tractor is effectively used for plowing, sowing, digging and trenching, mowing hay, clearing grass and snow, as well as for transport and loading operations.

The power unit consists of a four-cylinder, 4-stroke diesel engine with a liquid cooling system and direct fuel injection. Rated power — 40 hp (29.4 kW). Engine displacement — 2543 cm³, cylinder bore and piston stroke — 90 × 100 mm. Rated crankshaft speed — 2400 rpm. Engine start — electric starter with safe start, ensuring quick and reliable starting in all conditions.

The transmission is mechanical: (4 + 1) × 2, providing a wide range of speeds for field and transport tasks. Theoretical travel speed: forward — 1.75 - 32.2 km/h, reverse — 2.3 - 11.92 km/h. The PTO operates at 540/720 rpm.

The fuel system is equipped with an in-line plunger fuel pump. Rated fuel consumption — ≤ 255 g/kWh. Type of engine oil — mineral or semi-synthetic for diesel engines; rated oil consumption — ≤ 2.04 g/kWh. Fuel tank capacity — 28 L. Engine crankcase capacity — 5 L, transmission and rear axle crankcase — 25 L, front axle crankcase — 6.6 L. Engine cooling system capacity — 12 L.

Chassis and transmission: 4 × 4 all-wheel drive with rear differential lock. Clutch — dry, dual-disc. Brake mechanism is drum-type; disc brakes are installed for increased safety. Steering is equipped with power steering, simplifying work in confined spaces. Type of oil in transmission and rear axle — mineral, in front axle — transmission oil.

Hydraulic system with gear pump (pump type — gear). Fan and other units are driven by a V-belt transmission. Maximum lifting capacity of the hitch mechanism — 665 kg. Minimum ground clearance — 378 mm. Wheelbase — 1818 mm. Rear wheel track: 1100 (base); 1200; 1300; 1400 mm, front — 1200 mm. Tire size: rear — 7.5 × 16, front — 12.4 × 24.

Comfort and design: shock-absorbing seat to reduce vibrations, cabin heater for cold weather operation, adjustable rear wheels. Tractor structural weight — 1485 kg. Minimum turning radius with one-sided braking — 3.2 m. Rated traction force — 7.86 kN. Cooling system fan drive — V-belt transmission.

Dimensions in the description are stated as 3460 × 1510 × 1540 mm, while the specification table shows 3354 × 1500 × 2300 mm (L × W × H). The volume of the lift housing in the table is indicated as "-". Please consider both dimension values when selecting attachments and ensuring size compatibility.

Operational advantages: compactness and modern design, ease of maintenance, durability, and a wide network of spare parts, ensuring quick repairs and service in Ukraine. You can buy the Dongfeng DF 404D mini tractor at an attractive price in our online store — a reliable solution for farms and the utility sector.

We also recommend considering other models: Jinma 404, Shifeng 354, Dongfeng, Xingtai, Foton, Zoomlion, DTZ 5244, Bulat 454, Bulat 250, Bulat 254, Belarus 320.4, Shifeng 350, DW 244, DTZ 5404K, Solis 26, Solis RX 50.

Technical Specifications

Other important information: a comfortable shock-absorbing seat, cabin heater, adjustable rear wheels, and a hydraulic system with a gear pump make the Dongfeng DF 404D a versatile and productive helper on the farm.
