Mini Tractor DTZ 504KKU — Versatile and Reliable Equipment for Farms and Households

Manufacturer: DTZ. Model: Mini Tractor DTZ 504KKU. Category: Tractors > Mini Tractors. This model is designed for efficient work in the field, on homestead plots, and for transport tasks. The design combines a powerful diesel engine, a reliable transmission, and a robust chassis, ensuring a long service life and stable performance.

Key advantages at a glance:

• Powerful CF4B50T-Z diesel engine — 50 hp (36.78 kW) with a displacement of 2835 cm3 and 4 vertical cylinders.
• Electric starter for quick ignition and a closed liquid cooling system with forced circulation.
• Reliable transmission and rear differential lock for working in challenging conditions.
• Rear splined power take-off (PTO) shaft with 540/1000 rpm modes for a wide range of mounted and trailed equipment.
• Disc brakes on the rear wheels and a minimum ground clearance of 380 mm for maneuverability and safety.

The CF4B50T-Z engine is a diesel, 4-stroke, direct injection, non-turbocharged unit. Nominal crankshaft speed — 2400 rpm. Nominal fuel consumption — ≤ 243 g/kWh, nominal engine oil consumption — 1.6 g/kWh. Recommended oil — mineral or semi-synthetic for diesel engines. Fan drive system — V-belt transmission.

Traction and transmission characteristics: nominal traction force — 13.5 kN. The gearbox has a (4x2)+(4x2) scheme. Clutch — dry, 2-disc, constantly closed type. Main drive — direct. Types of transmission oil: Silver SAE 85W-90; Gold SAE 80W-90; Platinum SAE 75W-90 — used in the gearbox, rear, and front axles. The rear differential is equipped with a lock.

Hydraulics and PTO: power take-off shaft — rear, splined; PTO speed — 540 / 1000 rpm. Hydraulic system pump type — gear pump. Maximum lifting capacity of the mounted mechanism — 800 kg. Number of hydraulic outlets — 2.

Chassis and wheels: wheel formula 4x4, wheelbase — 2020 mm. Front wheel track available in values 1330, 1410, 1490 mm; rear — 1200, 1280, 1380, 1660 mm. Front tire size: 8.30-20; rear: 12.4-28. Minimum turning radius without brakes — 4.9 m, with brakes — 4.2 m. Travel speed: forward — 1.8-28.7 km/h, reverse — 0.5-16.3 km/h.

Capacities and weights: fuel tank volume — 46 L; engine crankcase volume — 7 L; front axle crankcase volume — 7.0 L; engine cooling system volume — 14.0 L. Rear weights — 6x45 kg; front weights — 4x30 kg. Overall dimensions (L x W x H): 4080x1610x2500 mm. Curb weight — 2640 kg. Minimum ground clearance — 380 mm ensures operation on uneven terrain and with mounted equipment.

Purpose and application: the DTZ 504KKU model is suitable for various agricultural and municipal tasks: plowing and cultivation, soil preparation, aggregation with mounted and trailed implements, cargo transportation, working with trailers and other units. The reliable transmission, powerful engine, and disc brakes ensure safety and durability in various operating conditions.

Technical specifications:

The DTZ 504KKU mini tractor is an optimal solution for those seeking versatile, powerful, and reliable equipment for agricultural or municipal farming. It combines high performance, fuel efficiency, and ease of maintenance.
