Product Code: FA103-18346-103
64 206 грн.
Buy this product in 1 click:
Main specifications
Beam thickness:
5 mm
Bottom Plate:
2.5 mm
Camera mount size:
19.3 mm (standard FPV micro/mini camera)
Central mounting diagram:
20×20 mm (M3) / 30.5×30.5 mm (M3)
Compatibility:
FPV Quadcopters 5", 7", 8", 9", 10"
All specifications
We will deliver this product:
Payment
Description
*** Minimum order - 3000 UAH! Ships from a remote warehouse. Shipping times 2-5 days.
An inexpensive and high-quality version of the Mark4 frame in 5/7/8/9/10 inch sizes, ideal for long-range freestyle FPV flights.
Specifications
- Model: Mark4 5" 225mm
- Weight: 102g
- Frame size (motor-to-motor wheelbase): 225mm
- Size: 145x172mm
- Arm thickness: 5 mm
- Side plates: 2.5 mm
- Top plate: 2.5 mm
- Bottom plate: 2.5 mm
- Camera mount size: 19.3 mm
- Model: Mark4 7" 295mm
- Weight: 121g
- Frame size (motor-to-motor wheelbase): 295mm
- Size: 193x223mm
- Arm thickness: 5 mm
- Side plates: 2.5 mm
- Top plate: 2.5 mm
- Bottom plate: 2.5 mm
- Camera mount size: 19.3 mm
- Frame size (motor-to-motor wheelbase) (specified in option):
- 295mm (7 inches) / 367mm (8 inches) / 387mm (9 inches) / 427mm (10 inches)
Recommendations
- Flight controller: RF/Kiss/F3/F4/F7
- For Mark4 5" (225mm):
- Motors: 2205/2206/2207/2305/2306
- ESC: 30A-50A
- Propellers: 5"
- Batteries: 4S 1500mAh-6s 11 50mAh
- For Mark4 7" (295mm):
- Motors: 2305/2306/2407/2408/2507
- ESC: 40A-60A
- Propellers: 7"
- Batteries: 4S 1800mAh-6S 2200mAh
Package Contents
- 1x Mark4 frame kit
Files
- Assembly instructions for Mark IV 10-inch carbon frame (Mark IV 10inches)
Specifications
Beam thickness
5 mm
Bottom Plate
2.5 mm
Camera mount size
19.3 mm (standard FPV micro/mini camera)
Central mounting diagram
20×20 mm (M3) / 30.5×30.5 mm (M3)
Compatibility
FPV Quadcopters 5", 7", 8", 9", 10"
Kit Contents
Mark4 carbon frame (selected size), mounting kit (screws, standoffs), mounting hardware, basic fittings
Materials
Carbon Fiber
Motor-to-motor diagonal size
225 mm / 295 mm / 367 mm / 387 mm / 427 mm
Mount type
Bolt-on assembly, universal mounting points for stack, VTX, and camera
Product type
Carbon frame for FPV drone
Rear Mounting Diagram
20×20 mm (M2) / 30.5×30.5 mm (M2)
Top Plate
2.5 mm
Type of Construction
X-type frame (freestyle / long-range FPV flights)
Weight
102 g (5") / 121 g (7")
Size
145×172 mm / 193×223 mm / ≈210×230 mm / ≈230×250 mm / ≈250×270 mm
