Product Code: FA94-24377-94
54 338 грн.
Buy this product in 1 click:
Main specifications
Battery storage temperature, °C: -20 ~ +40
BMS: JK Smart BMS 8-24S (24-72V) Ch200A Disch200A Bal cur 2A with Bluetooth
Charge operating temperature, °C: 0 ~ +40
Charging voltage (buffer mode), V: 55.2
Charging voltage (cyclic mode), V: 58.4
All specifications
We will deliver this product:
Payment
Description

This battery can be purchased as an additional battery for the LP Autonomic Ultra F5.0-5.2kWh Solar white with black backup power system, which will allow you to increase the autonomous operation time of the backup power system.

New generation LiFePO4 lithium batteries have high efficiency (up to 94%) and a wide operating temperature range (-15 ~ +60°C).

LiFePO4 batteries charge quickly, are completely sealed (can be operated in any position), and have compact dimensions.

The lithium battery, as an energy storage system, has a high level of environmental friendliness and a wide range of applications.

Compared to lead-acid batteries, LiFePO4 batteries have a longer service life (25 times), while being 2 times lighter than lead-acid batteries and having a high current output. This type of battery is non-combustible and non-toxic.

LiFePO4 batteries have a very low self-discharge, 20% of capacity, when stored for more than 10 years.

If you need a battery and don't know which one is better, choose lithium iron phosphate batteries from LogicPower.

Specifications
Battery storage temperature, °C -20 ~ +40
BMS JK Smart BMS 8-24S (24-72V) Ch200A Disch200A Bal cur 2A with Bluetooth
Charge operating temperature, °C 0 ~ +40
Charging voltage (buffer mode), V 55.2
Charging voltage (cyclic mode), V 58.4
Discharge operating temperature, °C -20 ~ +60
Full charge voltage, V 58.4
Internal resistance, mOm less than 0.5
Maximum charge current, A 100
Maximum discharge current, A 200
Minimum voltage, V 42
Nominal capacity, Ah 100
Nominal charging current, A 50
Nominal discharge current, A 50
Nominal values of elements 100
Nominal voltage, V 48 (51.2)
Number of cycles 7000
Number of elements in group S 16
Number of items in group R 1
Peak discharge current (100 ms), A 300
Short-circuit current, A 300
Starting current, A 300
Terminal type M8
Type LiFePO4
Warranty, months 60
