EW Diagnostic Device 100 - 2900 MHz MiNiON-Bob
Brand: Gedz Tech. MiNiON-Bob — a portable EW diagnostic device designed for rapid detection, monitoring, and analysis of electronic warfare sources in the operating range of 100 - 2900 MHz. The device combines compactness, portability, and professional software for monitoring interference levels in Scan mode with an audible alarm, allowing for quick detection of spectrum changes.
Device Advantages
- Accurate diagnosis of EW jammer operation due to a wide frequency range and sensitive detection.
- Portability — compact dimensions of 80x50x20 mm and light weight of 50 g ensure convenient carrying in a bag or pocket.
- Ease of use — intuitive interface and clear device operation algorithm.
- Specially developed software, not intended for public use, guarantees professional operation and confidentiality of settings.
- Scan mode with continuous monitoring of interference levels and audible alarm for prompt response to the appearance of obstacles.
Technical Specifications
- Operating Frequency Range: 100 - 2900 MHz.
- Built-in Display: OLED 1.3” 128x64 (monochrome) for displaying critical parameters and operating modes.
- Power Supply: built-in LiPo battery, capacity less than 450 mAh.
- Continuous Operation Time: at least 8 hours under typical usage conditions.
- Charging Port: USB Type-C for convenient and fast connection to power sources.
- Device Size: 80x50x20 mm — compact body that easily fits in a bag or pocket.
- Housing: metal (aluminum) — guarantees strength and reliability during long-term operation.
- Weight: 50 g — minimal weight for comfortable carrying.
The device is equipped with an SMA connector and is designed to detect enemy EW jammers; for operation in a specific sub-band, an additional antenna selected for the required frequency range is necessary. For diagnosing your own EW jammer, a standard antenna is included. Important: before testing your own EW jammer, do not use any antennas other than the standard one, otherwise the device may be irreversibly damaged.
MiNiON-Bob from Gedz Tech is ideal for engineers, technical specialists, operators, and mobile teams who need quick control over the presence and level of radio interference in a wide frequency range. Thanks to its compact size, light weight, and long battery life, this device is convenient for use in field conditions and at facilities where mobility and prompt diagnostics are important.
If you need a reliable, easy-to-use, and technically equipped device for detecting and analyzing EW in the 100 - 2900 MHz range — MiNiON-Bob from Gedz Tech meets these requirements.
