Anti-drone rifle by InterProinvest
Manufacturer: InterProinvest. This portable counter-UAV device is designed to protect objects from unauthorized use of low-altitude and low-speed drones by directional suppression of UAV communication and control channels in specified frequency ranges.
Capabilities overview
The device provides targeted electromagnetic radiation to typical control and navigation channels of modern drones: GPS, GLONASS, GALILEO, BEIDOU, 2.4 Wi-Fi, 5.8 Wi-Fi, and Bluetooth. The system effectively blocks control and data transmission, ensuring object protection at distances up to 3000 meters depending on terrain conditions, UAV type, and environment. Thanks to a directional antenna with a 30° beamwidth, the achievable range can reach up to 3000 m in favorable conditions.
Key technical parameters
- Total radiation power: up to 85 W.
- Continuous operation time: no more than 30 min. at +20°С.
- Operating temperature range: from -20°С to +35°С.
- Relative humidity: up to 100% at +25°С.
- Cooling system: air, passive.
- Range: up to 3000 m (with directional antenna, 30° beamwidth).
- Dimensions: 840 mm × 254 mm × 211 mm.
- Weight: no more than 6 kg.
- Mean Time Between Failures (MTBF): no less than 2000 hours.
Areas of application
The solution is recommended for protecting critical infrastructure, military bases, checkpoints, preventing illegal border crossings, and ensuring security during mass public events. The device is suitable for use in both stationary and mobile security conditions and can be integrated into an existing object security system.
Complex models and extended characteristics
Below is a complete table of characteristics for the portable, mobile, and stationary RIFF family complexes for easy reference:
| Portable RIFF family complex | |
| Range: | up to 1.5 km |
| RF output power: | 100 W (4 bands) |
| Weight: | Up to 5 kg |
| Mobile RIFF-M complex | |
| Range: | up to 3 km |
| Detection: | up to 5 km |
| RF output power: | 1 kW (8 bands) |
| Autonomous operation time: | 24 hours |
| Antenna: | omnidirectional (360°) |
| Stationary RIFF-S complex | |
| Range: | up to 3 km |
| Detection: | up to 5 km |
| RF output power: | 1 kW (8 bands) |
| Autonomous operation time: | 24 hours |
| Antenna: | omnidirectional (360°) |
| Additional options: | - Module for radio monitoring of all adjacent channels - Database for recording interference incidents - Creation of maps with detection and counter-drone zones |
If necessary, the system can be integrated into the object's security infrastructure and supplemented with software tools for incident logging and mapping of interference zones. The availability of portable, mobile, or stationary options allows choosing the optimal configuration depending on the requirements for range, power, and autonomy.
Advantages
- Targeted impact on main drone navigation and communication systems (GPS, GLONASS, GALILEO, BEIDOU, 2.4/5.8 Wi-Fi, Bluetooth).
- Configurable options: portable, mobile, or stationary.
- High output power in mobile and stationary versions (up to 1 kW) for extended range.
- Options for radio monitoring and incident analytics, recording logs, and mapping interference zones.
As an official InterProinvest product, this portable RIFF family complex combines mobility and effective counter-UAV capabilities in challenging operating conditions, ensuring reliable protection of objects for various purposes.
