Agro-drone FPVXSF JK6-30 30L Plant Protection Aircraft

The FPVXSF JK6-30 agro-drone is a professional plant protection aircraft with a 30L tank capacity, designed for efficient and precise application of liquid agents over large areas. This unit combines a modular design with aviation-grade carbon fiber and aluminum components, ensuring high strength, corrosion resistance, and a long service life. Delivery time is 15 to 30 days.

Key Advantages and Features

• Fully autonomous operation with the ability to perform tasks completely automatically;
• Automatic drone guidance and autonomous route planning for optimal field coverage;
• Automatic obstacle avoidance system and support for night flight mode;
• AB-point memory and breakpoint memory with the ability to resume spraying from that point;
• Bottom folding for convenient transport and compact dimensions when folded;
• 50mm carbon arms, 34-inch folding propellers, and enhanced fall protection;
• Powerful 14S28000 mAh battery (high-voltage version); batteries: 14S28000 mAh;
• Aerosol nozzle with 8 L/min flow and excellent atomization; spraying system: aerosol/nozzle;
• Standard remote controller with a 5.5-inch high-brightness screen for convenient monitoring;
• High-pressure brushless pump and fully waterproof ESC; fully waterproof casing;
• Can hover in any position, ensuring high stability during treatment.

Technical Specifications

• Material: aviation-grade carbon fiber + aluminum;
• Wheelbase: 1850 mm;
• Folded size: 1100×850×850 mm;
• Drone weight: 22 kg;
• Tank volume: 30 L;
• Payload mentioned as 27 kg (in some sources); maximum takeoff weight specified as 59 kg, in another section the parameter is stated as 65 kg;
• Maximum load: 30 kg;
• Flight height: ≤20 m;
• Flight radius: ≤5000 m;
• Flight time: 10–20 min; endurance at full load: 6–8 min;
• Flight speed: 1–12 m/s;
• Spraying speed: 4–8 L/min; spraying width according to various data: basic 5 m, maximum 7 m; working spraying width in parameters: 7–9 m;
• Power resource: ≥100,000 hours;
• Frame resource: ≥10 years;
• Safe wind speed: ≤7 points;
• Charging system: high-speed smart charging;
• Power unit: X9;
• Propellers: 34-inch folding.

Flight Modes and Additional Functions

• Control modes: manual, intelligent, fully automatic;
• Automatic return under normal conditions, upon signal loss, and at low battery;
• Integrated GPS, video transmission, and compatibility with ground station for planning and monitoring;
• Optional: terrain following, wave radar, automatic altitude setting;
• After-sales service and night mode operation capability.

The FPVXSF JK6-30 is designed for professional farmers and service companies requiring a reliable, waterproof, and quick-to-maintain aircraft for treating large areas. Thanks to its modular design and compact folded size, the agro-drone easily integrates into technological processes for applying crop protection products and fertilizers, ensuring precision, saving working time, and high productivity.

By ordering this agro-drone, you receive a fully autonomous system with intelligent route planning, an efficient spraying system, and a long operational life. Pay attention to the 14S28000 mAh battery specification and high-speed charging, which ensure quick preparation for the next work cycle.

Brand: FPVXSF; product category: Drones & Quadcopters > Agro-drones.
