YTO EMF504 Tractor — A Reliable Solution for Farm and Commercial Use

Brand: YTO. Product Type: Tractors, Motorcycles, ATVs, Boats (Vehicle) > Tractors > Mini Tractors. The YTO EMF504 model combines a proven design with modern technical solutions, making it a versatile mini tractor for soil cultivation, cargo transportation, work with attachments, and municipal tasks. This machine is designed for both private farms and agricultural enterprises.

The heart of the tractor is a 4-cylinder Xinchai 495 diesel engine (PERKINS license) with a power of 50 hp (36.8 kW), a displacement of 2.7 L, and a nominal crankshaft speed of 2400 rpm. The efficient air purification system features an external filter with an oil bath. The clutch is a single-disc, double-acting type with a diameter of 10''. The transmission is mechanical with a (4+4)x2 configuration, providing a wide range of speeds: forward 2.6-32.48 km/h and reverse 3.98-11.22 km/h.

The hydraulic system is combined and has 2 pairs of hydraulic outlets; the hydraulic pump type is a gear pump driven by the engine. The PTO delivers 29.5 kW of power and operates at 540/1000 rpm (6- and 8-spline shafts). The lifting capacity of the hitch mechanism is 950 kg, and the hydraulic system's flow rate is 25 L/min. Mechanical locking of the rear differential enhances off-road capability and traction in difficult conditions.

Technical Specifications:

Advantages of the YTO EMF504 include a powerful 29.5 kW PTO with 540/1000 rpm modes for a wide range of attachments, a sufficient lifting capacity of 950 kg, a reliable and productive 25 L/min hydraulic system, mechanical differential lock for improved traction, 350 mm ground clearance, and compact dimensions of 3750x1700x2500 mm, ensuring maneuverability in the field and confined areas. Disc brakes in an oil bath with hydraulic drive guarantee safe transport and operation in difficult conditions.

Operator comfort is ensured by a sealed cabin with filters, a cabin heater, and an optional air conditioner; additionally, a fire extinguisher stand and a toolbox are provided. The 50 L fuel tank allows for long operating times without frequent refueling, and the well-thought-out design and quality components ensure simple maintenance and long service life.

The YTO EMF504 is an ideal choice for those seeking a balance between power, versatility, and economy. The model is suitable for private farms, agricultural enterprises, and municipal services that require a reliable and multifunctional mini tractor.
