KENTAVR 160 BN Mototractor

The KENTAVR 160 BN mototractor from the manufacturer KENTAVR is a reliable and multifunctional assistant for farmers, private households, and municipal works. It belongs to the category Tractors > Mototractors. This model combines an economical diesel engine, a well-designed transmission, and a robust construction: compact dimensions of 2200x1100x1770 mm and a structural weight of 490 kg ensure stability when working with trailed and mounted equipment, while a ground clearance of 250 mm allows confident operation on various fields.

Engine and Start-up: Equipped with a horizontally positioned JD-16 model engine — a 195NL four-stroke diesel engine with water cooling. The engine displacement is 709 cm3, nominal power is 15 hp, and nominal speed is 2300 rpm. The cooling system is a condenser, and the flywheel rotation direction is counter-clockwise. Lubrication is performed via a gear pump with a splash lubrication system; the engine weight is 150 kg. The starting method is combined: electric starter and manual start (Z-handle), which enhances mobility in various operating conditions.

Transmission and Running Gear: The clutch is single-disc, dry type, with constant friction-type engagement. The combined-type gearbox ((3 + 1) * 2) with cylindrical gear drive provides optimal gears for field and transport work. The final drive is a single-stage, straight-tooth cylindrical gear drive. The braking system features 2 drum brakes; the oil volume in the gearbox is 5 L.

Wheels and Track Adjustment: Rear wheels size 6.5-16 with a chevron tread pattern for better grip in the field; front wheels are 5.00-12. The front wheel track is available in three options: 1100, 1200, 1300 mm; the rear wheel track is adjustable within 900-1300 mm, allowing the equipment to be adapted to various crops and working conditions.

Dimensions and Weights: Overall dimensions without mounted equipment — 2200x1100x1770 mm, ground clearance — 250 mm, structural weight of the mototractor — 490 kg.

Technical Specifications

Advantages and Applications

• Economical diesel engine with water cooling ensures long-term operation, stable power, and durability in intensive mode.
• Variable front wheel tracks and adjustable rear wheel track (900-1300 mm), along with chevron-tread tires, provide excellent grip and maneuverability in the field and on rough terrain.
• Reliable transmission, single-stage final drive, and robust gearbox withstand intensive loads when working with mounted equipment.
• Combined start-up (electric starter and manual start) guarantees quick engine start in various climatic conditions.

The KENTAVR 160 BN mototractor is ideal for cultivating small and medium-sized fields, soil preparation, cargo transportation, and working with trailed and mounted equipment. Thanks to its well-thought-out design and technical solutions, this model demonstrates stable performance in various climatic conditions and during prolonged operation. For additional information on configuration, prices, or available mounted equipment, please contact our managers or browse other models in the category.
