Description and Reviews of DW 150 RXi
Mototractor DW 150 RXi is a modernized and improved version of the popular 120 model, created to meet the needs of farmers, gardeners, and utility services. Brand: DW. Product type: Tractors, Moto, ATVs, Boats (Vehicle) > Tractors > Mototractors. This mototractor combines increased component strength, operator convenience, and versatility in application: from soil cultivation and plot preparation to snow removal and cargo transportation.
Design Features
The DW 150 RXi features adjustable front and rear track, increased half-axle diameter, and reinforced hubs, which enhances reliability during intensive use. The hydraulic system has a floating mode, both hand and foot throttles are available for convenient engine control, and mechanical steering ensures ease of maintenance. Despite a curb weight of 459 kg, the unit is highly maneuverable even on difficult terrains.
Off-road Capability and Traction
The chevron tread of the rear wheels guarantees excellent grip on the soil surface, which, combined with increased stability, reduces the risk of overturning. Operator comfort is provided by a soft seat with height adjustment, while powerful headlights and wide-angle mirrors improve safety during evening work and in conditions of limited visibility.
Functional Advantages
The DW 150 RXi is versatile in application: it can work with mounted and trailed equipment, be used for snow removal, loading and unloading operations, transportation of oversized cargo, and drilling. It has a sensor panel for monitoring coolant temperature, oil pressure, and current (ammeter). Equipped with powerful headlights, marker lights, a horn, and wide-angle mirrors, making it suitable for work in various conditions.
Economy and Service
The main advantages of the model are its competitive price compared to analogues, economical fuel consumption, and ease of finding spare parts. Ukrainian assembly, high-quality components, and high durability of units are confirmed by reviews from experienced users. Our online store is an official dealer, so you can buy a mototractor from us quickly and profitably: professional consulting engineers will help you choose the necessary configuration, and managers will arrange delivery to any region of the country.
We also recommend mototractors:
- Bulat
- Bulat T25
- Bulat 120
- Bulat 150
- Garden Scout
- Scout T15
- Scout T18
- Scout T25
- Scout 24
- Tractor Fighter
- Fighter T15
- Fighter T18
- Fighter T16
- Tractor Forte
- Forte T161
- Forte T181
- Forte T241
- Tractor DTZ
- DTZ 180
- Shifeng 240
Technical specifications of DW 150:
| Engine model | DD15VE |
| Engine power, hp (kW) | 15 (11.1) |
| Wheel formula | 4x2 |
| Engine type | diesel, 4-stroke, with direct injection, non-turbocharged |
| Number and arrangement of cylinders | 1, horizontal |
| Engine start system | electric starter, manual starter |
| Cooling system | water cooling, radiator type |
| Engine displacement, cm³ | 694 |
| Cylinder bore / piston stroke, mm | 95/98 |
| Nominal engine fuel consumption, g/kWh | 252 |
| Nominal crankshaft speed, rpm | 2300 |
| Nominal traction force, kN | 3.1 |
| Engine oil type | mineral or semi-synthetic for diesel engines |
| Nominal engine oil consumption, g/kWh | 1.5 |
| Gearbox (GP) | (3 + 1) x2 |
| Oil type for gearbox and reducer | Silver SAE 85W-90; Gold SAE 80W-90; Platinum SAE 75W-90 (transmission) |
| Rear differential lock | none, rear half-axle unlocking system |
| Clutch | dry, 2-disc, constantly closed type |
| Main drive | V-belt |
| Driven wheel drive | spur gear transmission |
| Steering | mechanical |
| Brakes | on rear wheels, drum brakes |
| Power take-off (PTO) | gearbox gear via intermediate reducer or from clutch pulley |
| PTO speed, rpm | 1180 |
| Maximum lifting capacity of mounted mechanism, kg | 120 |
| Minimum ground clearance, mm | 240 |
| Wheelbase, mm | 1200 |
| Track width, mm | front: stepped adjustment 950/1000/1050/1100/1150/1200; rear: stepless (smooth) adjustment 950...1320 |
| Tire size | front 5.00-12 (herringbone); rear 6.50-16 |
| Minimum turning radius, m | without brakes 2.3; with brakes 1.8 |
| Travel speed, km/h | forward 2.24-22.78; reverse 1.72-6.97 |
| Fuel tank volume, L | 7.7 |
| Engine crankcase volume, L | 2.0 |
| Gearbox and reducer crankcase volume, L | 5.0 |
| Engine cooling system volume, L | 2.5 |
| Overall dimensions (L x W x H), mm | 2200x1090x1300 |
| Curb weight, kg | 459 |
The DW 150 RXi will be a reliable assistant on the farm thanks to its combination of a powerful diesel engine, versatility of mounted equipment, and availability of service components. If you are looking for an optimal balance of price, reliability, and ease of operation, this model deserves attention.
