Shifeng SF-220 Mototractor — Overview and Specifications

Shifeng SF-220 is a reliable mototractor from the manufacturer Shifeng, designed for use on small farms, private households, and individual applications. The model combines good power, versatility, and an affordable price, making it popular among small agricultural producers. Product category: Tractors, Motorcycles, ATVs, Boats (Vehicle) > Tractors > Mototractors.

Engine and Transmission

The mototractor is equipped with a single-cylinder four-stroke engine, model 138-2, with a nominal power of 22 hp and a maximum power of 24 hp. The engine is started by an electric starter and manual start (Z-shaped handle). The cylinder diameter is 115 mm, and the piston stroke is 125 mm. The fuel tank capacity is 12 L, and the operating speed is 2200 rpm. The cooling system is water-cooled, and the lubrication system is a gear pump. In the basic configuration, the PTO type is a pulley on the flywheel. The engine weight is 230 kg, and the engine dimensions are 820 x 530 x 750 mm.

The transmission is mechanical, with a (3+1) × 2 gearbox, ensuring comfortable operation and forward movement at speeds up to 30 km/h. Power is transmitted from the engine by a pair of V-belts under constant tension. Speed shifting is mechanical.

Chassis, Wheels, and Braking

The mototractor's track is non-adjustable: the front axle width is 117 cm, the rear is 120 cm, and the wheelbase is 140 cm. The front wheels are 4.0" x 14" with a less pronounced tread for better rolling, while the rear wheels are 7.5" x 20" with a quality tread for reliable grip on the ground. Ground clearance is 320 mm. The brake type is disc brakes. The clutch system is dry, dual-disc.

Standard equipment includes front and rear ballast, and a towing hitch for a trailer. The minimum turning radius is 2.2 m, allowing work in confined spaces.

Electrical Equipment and Instruments

Lighting includes two headlights with high and low beams, turn signals, and marker lights. There is a horn. The dashboard features a voltmeter, temperature gauge, and oil pressure gauge, providing control over key engine parameters during operation.

Attachment Compatibility

The Shifeng SF-220 is compatible with main types of trailed and mounted agricultural equipment: plows, cultivators, potato diggers, trailers, and other implements. Due to the non-adjustable track, some types of mounted equipment may require additional adjustment of mounting positions.

Model Advantages:

• Powerful single-cylinder engine up to 24 hp (max) at an affordable price;
• Reliable mechanical gearbox with (3+1)×2 gear formula for various operating modes;
• Disc brake system and dry dual-disc clutch enhance operational safety;
• Versatility: tillage, cargo transport, work with mounted and trailed equipment.

Payment for the goods is made by full payment or credit is available. Delivery across Ukraine is available (free delivery is specified in the original description).

Recommended similar models: Bulat, Bulat t25, Bulat 120, Bulat 150, Garden Scout, Scout t15, Scout t18, Scout t25, Scout 24, Tractor Fighter, Fighter t15, Fighter t18, Fighter t16, Tractor Forte, Forte t161, Forte t181, Forte t241, Tractor DTZ, DTZ 180, Shifeng 240.

Shifeng SF-220 Specifications:

The Shifeng SF-220 model is an optimal solution for those seeking a combination of power, reliability, and cost-effectiveness. Thanks to its versatility and compatibility with main mounted implements, this mototractor will be a useful tool in your household.
