Technical Specifications

General Information

Visible Diagonal: 31.6"
Active Screen Area (H x V):

• 699.48 × 394.73 mm
• 27.54 × 15.54"
• Area: 276,105.74 mm² (427.97 in²)

Panel and Image

Panel Type: QD-OLED
Screen Coating: Anti-reflection
Max Resolution: 4K UHD (3840 × 2160) @ 240 Hz (DSC, visually lossless)
Aspect Ratio: 16:9
Pixel Pitch: 0.1814 × 0.1814 mm
Pixel Density (PPI): 140
Contrast Ratio: 1,000,000:1 (SDR and HDR)
Brightness: up to 1000 cd/m² (HDR peak)
Viewing Angles: 178° / 178°
Color Depth: 1.07 billion colors
Color Gamut: DCI-P3 99%
Backlight: OLED
Response Time: 0.03 ms (GTG minimum)

Connectivity

Rear Ports:

• 1 × DisplayPort 1.4 (HDCP 1.4 & 2.3, up to 4K 240 Hz, DSC, HDR)
• 2 × HDMI 2.1 (HDCP 1.4 & 2.3, up to 4K 240 Hz FRL, HDR, VRR, eARC on one port with Dolby Atmos pass-through support)
• 1 × USB 3.2 Gen 1 Type-B (upstream)
• 2 × USB 3.2 Gen 1 Type-A (downstream)

Quick Access:

• 1 × USB 3.2 Gen 1 Type-C (downstream, BC1.2 charging)
• 1 × USB 3.2 Gen 1 Type-A (downstream)

Audio Output: none
Built-in Speakers: none

Image Synchronization

• NVIDIA G-SYNC Compatible: yes
• AMD FreeSync Premium: no
• VESA AdaptiveSync: yes

Ergonomics and Design

Adjustments: height, tilt, swivel, cable management
Height Adjustment: 110 mm
Tilt: -5° / +21°
Swivel: -20° / +20°
Pivot: none
Lighting: AlienFX Lighting
VESA Mount: 100 × 100 mm

Eye Protection

• ComfortView Plus (hardware solution)
• Flicker-free

Power Consumption

Input Voltage: 100–240V AC (50/60 Hz, 3A)
Operating Mode: 42.5 W
Maximum: 190 W
Standby Mode: 0.5 W
Off: 0.3 W

Operating Conditions

Temperature:

• Operating: 0°C – 40°C
• Storage: -20°C – 60°C

Humidity:

• 10% – 80% (operating)
• 5% – 90% (storage)

Altitude:

• up to 5000 m (operating)
• up to 12,192 m (non-operating)

Physical Characteristics

Dimensions with Stand: 18.61" – 22.94" (height adjustable)
Width: 28.17"
Depth: 12.04"

Without Stand:

• Height: 16.61"
• Width: 28.17"
• Depth: 4.19"

Panel Weight: 13.23 lb
Weight with Packaging: 31.72 lb

Package Contents

• Monitor
• Stand (stand riser and base)
• Microfiber cloth
• Quick setup guide
• Safety information
• Power cable
• HDMI 2.1 FRL cable
• DisplayPort cable
• USB 3.2 Gen 1 upstream cable

Additional Information

Compatibility: Dell Display Manager
Standards:

• EMC, Safety, Environmental Datasheets
• Dell Regulatory Compliance
• Dell Environmental Programmes
  VESA: 100 × 100 mm
