Foton TB-504 Mini Tractor with Cabin and Air Conditioner — Power and Comfort for Year-Round Work
The Foton TB-504 mini tractor from the manufacturer Foton is a versatile piece of equipment for agriculture, municipal services, and private farms. The TB-504 model is a modernized version of the basic 504 (updated in 2018) and combines reliable mechanics with the comfort of an enclosed cabin with air conditioning, allowing for cool operation in summer and additional protection from bad weather in winter.
Applications
The Foton TB-504 is effective for seasonal field work, lifting and transporting goods, and performing municipal tasks in cities and at industrial sites. The 4x4 all-wheel drive and power steering allow the tractor to be operated on rough terrain, in viscous soil, and on potholed roads, ensuring stability and control during maneuvering.
Key Advantages
- Cabin Comfort: An enclosed cabin with air conditioning increases operator productivity and makes work shifts more comfortable in any weather.
- Engine and Fuel Efficiency: A modern 4-cylinder diesel engine provides sufficient power with reasonable fuel consumption.
- Power: 50 hp (36.8 kW) — optimal for heavy field work and operation with attachments.
- Starting: An electric starter allows for easy engine starting in various temperature conditions.
- Transmission and Reverse: Gearbox with (4x3)+(4x3) scheme with reverse for convenient change of direction without a full stop.
- Power Take-Off (PTO): Independent 8-spline PTO, 540/1000 rpm for compatibility with various attachments.
Additionally, the mini tractor has a low specific fuel consumption of 245 g/kWh, a traction force of 10.8 kN, and a dry single-disc clutch. The adjustable track width of 1200-1500 mm and a minimum ground clearance of 280 mm make the machine adaptable to various tasks. The wheelbase is 1990 mm, and the dimensions are: length 3980 mm, width 1750 mm, height 2500 mm. Wheel sizes: rear 12.4x28, front 8.3x20.
Cabin Configuration: The presence of an enclosed cabin with air conditioning enhances operator safety and comfort, which is especially important during prolonged operation in extreme weather conditions.
By purchasing the Foton TB-504 from the Flash Army online store, you receive not only a modern tractor but also service: free delivery across Ukraine, warranty service, and technical support by phone. Our specialists will help you choose suitable attachments and provide qualified advice on the operation and maintenance of the machine.
Specifications
Engine model | 4-cylinder | |
Number of cylinders | 4 | |
Diesel engine power, hp / kW | 50/36.8 | |
Specific fuel consumption, g / kWh | 245 | |
Engine start type | electric starter | |
Tractor traction force, kN | 10.8 | |
Transmission type | 4x4 | |
PTO type | independent | |
Number of PTO splines | 8 | |
PTO speed, rpm | 540/1000 | |
Steering | hydraulic | |
External hydraulics | two channels | |
Cabin availability | yes | |
Clutch | dry single-disc | |
Track, mm | 1200-1500 | |
Wheelbase, mm | 1990 | |
Minimum ground clearance, mm | 280 | |
Rear wheel size | 12.4x28 | |
Front wheel size | 8.3x20 | |
Overall dimensions, mm | length | 3980 |
width | 1750 | |
height | 2500 | |
Number of transmission speeds | (4x3)+(4x3) | |
Air conditioner | yes | |
The Foton TB-504 is a reliable choice for those who value a combination of power, functionality, and operator comfort. Contact Flash Army, and we will help you choose the optimal configuration, arrange delivery across Ukraine, and provide quality service.
