Mini Tractor DW 404 ADC — Overview and Key Features

The DW 404 ADC mini tractor from manufacturer DW is a versatile and reliable unit for agriculture, municipal work, and private farming. This model combines high traction, an economical diesel engine, and well-designed cabin ergonomics for long shifts. Thanks to a wide field of view and a full-size sealed cabin with an adjustable seat, the operator works comfortably in all conditions.

The DW 404 ADC is equipped with a vertical four-cylinder diesel engine, model 4L22BT, with a displacement of 2543 cm3 and power up to 40 hp (29.3 kW). The engine is four-stroke with a forced liquid cooling system and direct fuel injection, which increases its lifespan and stability during intensive operation. Starting is done by electric starter, nominal crankshaft speed is 2350 rpm, cylinder diameter/piston stroke is 90 x 1000.

The fuel supply system is a plunger-type in-line pump, with nominal fuel consumption not exceeding ≤242 g/kWh. The recommended engine oil is mineral or semi-synthetic for diesel engines. Transmission oils are used for the transmission, front and rear axles; the clutch is dry, dual-disc.

Transmission, Cross-Country Capability, and Attachments

The gearbox is an upgraded (4+1)x2 type, the cooling system fan drive is a V-belt transmission, and the braking mechanism is drum-type. The 4x4 wheel formula, combined with rear differential lock and aggressive tire tread, ensures excellent cross-country capability and minimizes slippage in difficult conditions. The power take-off (PTO) shaft has speeds of 540 / 1000 rpm, the hydraulic system is equipped with a gear pump, and the maximum lifting capacity of the hitch mechanism is 550 kg. Minimum ground clearance is 320 mm.

Dimensions, Tires, and Speed Modes

The tractor's wheelbase is 1830 mm, rear wheel track is 1300-1560 mm, front wheel track is 1280-1480 mm. Tire size: rear — 11.20-24, front — 7.50-16. The minimum turning radius is 2.6 m with one-sided brake and 3.0 m without brake. Theoretical forward speed ranges from 0.39 to 31.97 km/h, reverse speed from 0.51 to 12.76 km/h.

Operating fluid volumes: fuel tank — 30.0 L, engine crankcase volume — 4.5 L, gearbox, rear axle, and lift crankcase volume — 18.0 L, front axle volume — 8.0 L, engine cooling system volume — 5.0 L. The tractor's curb weight is 1590 kg, overall dimensions (LxWxH) — 3350x1600x2350 mm.

Model Advantages

The DW 404 ADC attracts buyers with a range of practical advantages:

• High traction and power characteristics — 40 hp for a wide range of agricultural tasks;
• Economical engine with low fuel consumption;
• Full-size sealed cabin with good visibility and an adjustable seat for operator comfort;
• Convenient control layout, modern ergonomics, and full lighting for working in the dark;
• Differential lock, power steering with a separate pump and oil tank, and dual-mode PTO (540/1000 rpm).

Where to Buy

You can buy the DW 404 ADC mini tractor in the "Flash Army" online store. We offer an official warranty, free delivery across Ukraine, and payment options including cash, cashless, or credit. Returns are possible within 14 days. To place an order, leave your number in the form on the website or contact a manager — we will quickly clarify all details.

Technical Specifications:

If you need a reliable machine for various tasks on the farm or in municipal services — the DW 404 ADC combines power, efficiency, and comfortable operation.
