ADVANTAGES

- Used in heating systems with forced circulation of coolant (water) in premises (apartments, residential buildings, shops, etc.).

- Reduced noise level due to the use of a relay as a switching element

- Equipped with a circulation pump

- Three power regulation stages

- High-precision thermostat with 1°C hysteresis ensures smooth regulation and maintenance of coolant temperature and reduced energy consumption

- Over-temperature protection for the coolant

- Ability to connect a room thermostat and programmer

- Connection to the heating system: direct supply pipe (G3/4) – in the upper part of the boiler, return pipe (G1) – in the lower part

- Power connection and emergency status indication

- Steel tank and zinc-coated pipes, stainless steel heating elements ensure high corrosion resistance

- High-quality Wilo pump

- Enclosure protection rating – IP22

- Warranty – 24 months

- Extensive network of service centers

SPECIFICATIONS

Installation method: wall-mounted

Number of circuits: single-circuit (heating)

Heat output: 4.5 kW

Number of heating elements: 3

Number of power stages: 3 (1.5/3/4.5)

Connection type: single-phase

Supply voltage: 230 V

Maximum operating coolant temperature: 85° (±5)

Coating: zinc-coated steel

Control: mechanical

Enclosure protection rating: IP22

Protection class against electric shock: Class 1

Nominal operating pressure: 0.2 MPa

Coolant volume: 2.2 L

Device dimensions: 750x225x153 mm

Dimensions in packaging: 780x230x160 mm

Device weight: 11.2 kg

Weight in packaging: 12.2 kg

Country of manufacture: Ukraine

Brand registration country: Ukraine

Warranty: 24 months

Service life: 10 years

Color: white
