Forte JH-1200 Electric Cargo Tricycle
Brand: FORTE. The Forte JH-1200 electric cargo tricycle is a reliable and economical solution for transporting goods over short distances. This model combines a powerful electric motor with a well-designed dump body featuring tilting and drop sides, making work quick and convenient in warehouses, on farms, in public utilities, or for small businesses.
Performance and Electrical System
The 1200 W electric motor operates at 60 V, allowing for a maximum speed of up to 40 km/h. The 60/45 V/Ah (lead-acid, maintenance-free) battery provides a range of up to 45 km on a single charge under moderate loads. Full charging takes approximately 6-8 hours, enabling a workday to be planned with a single recharge.
Controls, Transmission, and Type
Engine type: electric. Gearbox: 3+3. Seating capacity: 1. Motorcycle type: cargo dump truck. The tilting body and drop sides (rear/left/right) simplify loading and unloading various types of cargo.
Running Characteristics
Front tires: 3.75-12; rear tires: 4.00-12. Brake system: front disc and rear drum, ensuring reliable braking under various loads. The front suspension features a telescopic fork with coil springs; the rear is a dependent suspension on semi-elliptic 7-leaf springs, guaranteeing stability and comfort when transporting goods.
Dimensions and Load Capacity
Body dimensions (LxWxH): 1500x1000x450 mm. Overall vehicle dimensions: 3000x1100x1720 mm. Load capacity: 500 kg. The device's curb weight is 290 kg, providing an optimal balance of payload and maneuverability.
Technical Parameters
| Engine power, W | 1200 |
| Engine voltage, V | 60 |
| Max. speed, km/h | 40 |
| Battery capacity, V/Ah | 60/45 |
| Range per charge, km | 45 |
| Engine type | electric |
| Number of gears | 3+3 |
| Seating capacity | 1 |
| Motorcycle type | cargo dump truck |
| Battery type | lead-acid, maintenance-free |
| Battery charging time, h | 6-8 |
| Tilting body | yes |
| Drop sides | rear/left/right |
| Front tire size, inches | 3.75-12 |
| Rear tire size, inches | 4.00-12 |
| Brakes (front/rear) | disc/drum |
| Front suspension | telescopic fork with coil springs |
| Rear suspension | dependent suspension on semi-elliptic 7-leaf springs |
| Body dimensions (LxWxH), mm | 1500x1000x450 |
| Overall dimensions (LxWxH), mm | 3000x1100x1720 |
| Load capacity, kg | 500 |
| Weight, kg | 290 |
The Forte JH-1200 is a practical electric vehicle for those who value economical operation, ease of maintenance (maintenance-free battery), and high payload capacity. The model is ideal for working in confined spaces: greenhouses, warehouses, production workshops, private farms, and public utilities. Thanks to the tilting body and drop sides, operation becomes maximally efficient when handling various types of cargo.
