Hyundai ELECTROGENO DHY66KSE Diesel Generator (53 kW) — Overview and Specifications
The Hyundai ELECTROGENO DHY66KSE (53 kW) diesel generator from Hyundai is designed to provide energy independence for commercial and industrial facilities. This model falls under the category: Energy Independence > Generators. It is a powerful three-phase power station that provides stable voltage of 380V / 220V at a frequency of 50 Hz and is suitable for most standard electricity consumers.
The unit's design features a reliable 4-cylinder, four-stroke engine with water cooling and turbocharging (engine model: HY4D85Z-D20, displacement 4200 cm3). The generator has an electric starter for convenient startup, a spacious fuel tank with a volume of 84 L, and an oil capacity of 11 L, ensuring long autonomous operation and reliable service life under intensive operating conditions.
Power and electrical parameters of the device: peak power 52.8 kW, continuous (rated) power 48 kW, rated current 79A. The generator is designed to operate at a frequency of 50 Hz with a three-phase configuration of 380V / 220V. The noise level during operation is 68 dB, and fuel consumption at 100% load is 14.8 L/h.
Device dimensions and weight: 2560x850x1300 mm (LxWxH), weight — 1150 kg, making it optimal for stationary installation in workshops, boiler rooms, or on specialized outdoor stands, provided it is protected from atmospheric influences.
Specifications:
| Number of phases: | 3 |
| Voltage: | 380V / 220V |
| Engine type: | 4-cylinder, four-stroke, water-cooled, turbocharged |
| Engine model: | HY4D85Z-D20 |
| Engine displacement: | 4200 cm3 |
| Starting system: | electric starter |
| Fuel tank capacity: | 84 L |
| Oil capacity: | 11 L |
| Peak power: | 52.8 kW |
| Continuous power: | 48 kW |
| Rated current: | 79A |
| Frequency: | 50 Hz |
| Noise level: | 68 dB |
| Fuel consumption (100% load): | 14.8 L/h |
| Dimensions, LxWxH: | 2560x850x1300 mm |
| Weight: | 1150 kg |
The advantages of the model include a reliable HY4D85Z-D20 turbodiesel engine, a high power reserve for peak loads, and economical fuel consumption at full load. The well-designed fuel and lubrication systems ensure ease of maintenance and a long service life for the unit.
Operating recommendations:
- Regularly check the oil level (11 L) and top up with the manufacturer's recommended oil type if necessary.
- Monitor fuel consumption and the condition of fuel and air filters to prevent power reduction and increased fuel consumption.
- Perform scheduled maintenance on the HY4D85Z-D20 engine, especially during intensive operating cycles.
- When selecting an automatic transfer switch (ATS), consider the rated current of 79A and the three-phase 380V configuration for correct operation of protection and control systems.
The Hyundai ELECTROGENO DHY66KSE is an optimal solution for those seeking a powerful and reliable diesel generator from a renowned manufacturer with clearly defined technical parameters and good operational characteristics. The model is suitable for backup power for facilities, electricity supply on construction sites, and agricultural enterprises.
