Product Code: FA94-31173-94
2 065 грн.
Buy this product in 1 click:
Main specifications
Battery storage temperature, °C: -15 ~ +50
BMS: is
Charge operating temperature, °C: 0 ~ +40
Charging voltage (buffer mode), V: 14.6
Charging voltage (cyclic mode), V: 14.6
All specifications
We will deliver this product:
Payment
Description

New generation LiFePO4 batteries have high efficiency (up to 94%) and a wide operating temperature range (-15 ~ +60°C).

LiFePO4 batteries charge quickly and have compact dimensions.

WARNING! Maximum discharge current 9.6 A!
WARNING! It is forbidden to connect LiFePO4 batteries in series!
WARNING! Not for use with UPS
WARNING! The GV LiFePO4 12V (12.8V) - 9 Ah (115 Wh) battery is forbidden for use as a starter battery in cars and other vehicles!
WARNING! It is forbidden to connect to devices designed for loads greater than 120W

As an energy storage system, the lithium battery has a high level of environmental friendliness and a wide range of applications.

Compared to lead-acid batteries, LiFePO4 batteries have a longer service life (25 times longer), while being 2 times lighter than lead-acid batteries and having a high current output. This type of battery is non-flammable and non-toxic.

LiFePO4 batteries have a very low self-discharge, 20% of capacity, when stored for over 10 years.

If you need a battery and don't know which is best, choose lithium iron phosphate batteries from GreenVision.

Quality guarantees and technical support

We provide a manufacturer's warranty for all types of batteries. Warranty repair and technical maintenance are carried out in certified service centers.

Specifications
Battery storage temperature, °C -15 ~ +50
BMS is
Charge operating temperature, °C 0 ~ +40
Charging voltage (buffer mode), V 14.6
Charging voltage (cyclic mode), V 14.6
Discharge operating temperature, °C -15 ~ +60
Full charge voltage, V 14.6
Height, mm 97
Housing material Plastic
Internal resistance, mOm 21
Length, mm 150
Maximum charge current, A 7.2
Maximum discharge current, A 9.6
Minimum voltage, V 10
Nominal capacity, Ah 12
Nominal capacity, mAh 12000
Nominal voltage, V 12 (12.8)
Number of cycles 5000
Peak discharge current (100 ms), A 100
Stored energy, Wh 154
Terminal type T2/F2
Type LiFePO4
Warranty, months 24
Weight, kg 1.35
Width, mm 100
