SKAUT TV-804S Tractor with Air Conditioner — Powerful and Comfortable 4x4 Mototractor
The SKAUT TV-804S tractor with air conditioner from the Skaut brand is a versatile 80 hp class mototractor designed for intensive use in fields, on farms, and in municipal utilities. Category: Tractors, Moto-, ATVs, Boats (Vehicle) > Tractors > Mototractors. The model combines high performance, fuel efficiency, and operator comfort thanks to its air conditioner and comfortable cabin.
At the heart of the tractor is a 3299 cm3 4-stroke diesel engine, Laidong KM4100ZT4-53 (Stage II), with four vertically arranged cylinders. The engine's nominal power is 80 hp (58.8 kW), and its nominal fuel consumption does not exceed ≤225 g/kWh. The starting system is an electric starter. This combination provides reliable traction with moderate fuel consumption for long hours of field work.
Key Technical Specifications and Capabilities
- 4x4 all-wheel drive with rear differential lock — for working in challenging soil and climatic conditions.
- Nominal traction force — 13.9 kN, ground clearance — 390 mm — confident obstacle negotiation.
- 12+12 gearbox provides a wide range of speeds for field and transport operations.
- Clutch — dry 2-disc constantly closed type for reliability and durability.
- Hydraulic steering and two hydraulic outlets allow for connecting various attachments.
- Rear hitch lifting capacity — 1880 kg, PTO — 540/1000 rpm for a wide range of implements.
- Comfortable cabin with air conditioner makes long work less tiring.
The cooling system is liquid, closed with forced circulation, which allows maintaining optimal engine temperature under intense loads. The main drive is direct. The braking system is located on the secondary shaft of the gearbox with brake drums. The power take-off shaft is rear, splined. The hydraulic system pump type is a gear pump (NSH) for hitch drive and NSH for power steering operation. A trailer connector (socket) is available.
| Engine power, hp (kW) | 80 (58.8) |
| Wheel formula | 4x4 |
| Engine type | diesel, 4-stroke, Laidong KM4100ZT4-53 (Stage II) |
| Number and arrangement of cylinders | 4, vertical |
| Engine starting system | electric starter |
| Cooling system | liquid, closed, with forced circulation of coolant |
| Engine displacement, cm3 | 3299 |
| Nominal engine fuel consumption, g/kWh | ≤225 |
| Nominal traction force, kN | 13.9 |
| Gearbox (КП) | 12+12 |
| Rear differential lock | + |
| Clutch | dry 2-disc constantly closed type |
| Main drive | direct |
| Steering | hydraulic |
| Brakes | on secondary gearbox shaft, brake drums |
| Power take-off (PTO) shaft | rear, splined |
| Hydraulic system pump type | gear pump (NSH) for hitch drive / NSH for power steering operation |
| Hitch lifting capacity | 1880 kg |
| Power take-off (PTO) shaft speed, rpm | 540 / 1000 |
| Wheel track | front 1440, rear 1310 |
| Tire size | front 9.5-24, rear 14.9-30 |
| Ground clearance, mm | 390 |
| Number of hydraulic outlets | 2 |
| Trailer connector (socket) | + |
| Dimensions LxWxH mm | 3950x1780x2710 |
| Curb weight, kg | 2950 |
The SKAUT TV-804S tractor with air conditioner is an excellent solution for owners of medium and large farms, municipal service enterprises, and industrial use. It is suitable for a wide range of operations: plowing, soil cultivation, sowing, connecting various mounted and trailed implements thanks to its powerful hydraulics and PTO. The combination of an 80 hp engine, 390 mm ground clearance, 4x4 all-wheel drive, and a capacious hydraulic system ensures reliable performance in challenging conditions.
