SADIN SD1204 Tractor — Powerful and Reliable Assistant for Heavy-Duty Work

Brand: SADIN. Category: Tractors > Mini Tractors. The SADIN SD1204 model combines high power, thoughtful design, and broad functionality, making it an optimal choice for agricultural, municipal, and industrial tasks.

The tractor is equipped with a Huafeng 4RMIZT28/CN III 4-stroke diesel engine with 120 hp (88.2 kW). The engine features 4 vertically arranged cylinders, an electric starter, and a closed liquid cooling system with forced circulation, ensuring stable operation in challenging conditions. The nominal traction force is 38.93 kN, and the lifting force of the mounted equipment is 23.5 kN, allowing for efficient work with heavy implements and aggregates.

Key Technical Specifications

• Engine power: 120 hp (88.2 kW)
• Wheel formula: 4x4
• Engine type: diesel, 4-stroke, Huafeng 4RMIZT28/CN III
• Number of cylinders: 4, vertical arrangement
• Starting system: electric starter
• Cooling system: liquid, closed with forced circulation
• Nominal traction force: 38.93 kN
• Transmission: 16+8
• Rear differential lock: yes
• Clutch: independent dry, double-acting
• Main drive: direct
• Steering: hydraulic
• Brakes: pneumatic braking system
• PTO: rear, splined (rpm 540/1000)
• Hydraulic pump type: gear pump for implement drive and power steering operation
• Mounted equipment lifting capacity: 2785 kg
• Tire size: front 14.9-26, rear 18.4-38
• Wheel track: front 1700/1780/1880, rear 1500-1800
• Ground clearance: 405 mm
• Number of hydraulic outlets: 3
• Trailer connector: yes
• Air conditioner: yes
• Dimensions (LxWxH): 4500x2220x2900 mm
• Curb weight: 4400 kg

The SADIN SD1204 is designed to meet the needs of owners who value versatility, reliability, and operator comfort. The powerful hydraulic system and high lifting capacity of mounted equipment allow the tractor to be effectively used with plows, cultivators, seeders, trailers, and other aggregates. The 16+8 transmission, combined with a direct main drive, ensures smooth gear shifting and stable traction both in the field and during road transport.

The rear differential lock improves проходимость in difficult soil or weather conditions. The independent dry double-acting clutch and hydraulic steering guarantee reliable operation. The pneumatic braking system ensures safe braking when driving with trailers and transporting loads, and the air conditioner creates comfortable conditions for the operator during long work shifts.

Technical solutions such as a splined rear power take-off shaft with 540/1000 rpm modes and a gear pump for implement drive and power steering make the SD1204 a versatile tool for a wide range of agricultural and municipal tasks. Dimensions of 4500x2220x2900 mm and a curb weight of 4400 kg ensure stability and maneuverability, while a ground clearance of 405 mm allows safe operation on uneven terrain.

Below is a complete table of technical specifications for easy reference:

The SADIN SD1204 tractor is ideal for farms, municipal services, and enterprises looking for a powerful, versatile, and comfortable tractor for daily operation. For detailed consultation on configuration, operational features, or available options, please contact the seller or an official SADIN dealer.
