Product Code: FA101-206381-101
In Stock
441 000 грн.
Buy this product in 1 click:
Main specifications
Clutch:
dry, dual-action
Cooling system fan drive:
V-belt drive
Engine Start:
electric starter with safe start
Engine type:
vertical, 4-cylinder, 4-stroke diesel with forced water cooling and direct injection
Front tire size:
7.50-16
All specifications
We will deliver this product:
Payment
Specifications
Clutch
dry, dual-action
Cooling system fan drive
V-belt drive
Engine Start
electric starter with safe start
Engine type
vertical, 4-cylinder, 4-stroke diesel with forced water cooling and direct injection
Front tire size
7.50-16
Front track, mm
1200, 1400
Fuel pump type
plunger, in-line
Fuel tank capacity, L
28
Gearbox
(4x2)+(4x2)
Hydraulic pump type
gear pump
Lift body volume, L
-
Loaded weight, kg
1780
Maximum payload capacity of the attachment mechanism, kg
665
Minimum turning radius with brakes, m
3.5±0.2
Minimum turning radius without brakes, m
4.0±0.2
Nominal engine crankshaft speed, rpm
2400
Nominal engine oil consumption, g/kWh
240
Nominal pulling force, kN
9.2
Overall dimensions (L x W x H), mm
3460x1570x2180
Power take-off (PTO) shaft speed, rpm
540/1000
Rated engine power, hp (kW)
40 (29.4)
Rear axle differential lock
Is
Rear Tire Size
12.4-24
Rear track, mm
1200, 1300, 1400, 1520
Steering
UP
Theoretical forward speed, km/h
1.47–25.01
Theoretical reverse speed, km/h
1.13—19.20
Wheel formula
4x4
Wheelbase, mm
1890
