TGB Blade 550 EPS — a modern ATV from TGB
TGB Blade 550 EPS is a versatile ATV from the TGB brand, combining a powerful engine, reliable transmission, and thoughtful ergonomics for both work and leisure. The model belongs to the category: Motor Vehicles > ATVs. The Blade 550 EPS is ideal for field work, towing, cargo transport, and active off-road routes.
At the heart of the ATV is a single-cylinder, 4-stroke, fuel-injected gasoline engine with a displacement of 503 cm³, developing 39 hp at 6500 rpm with a maximum torque of 46.1 Nm. The starting system is an electric starter, the ignition system is controlled by an ECU unit, and cooling is liquid. The powerful engine combined with a CVT variator ensures smooth acceleration and the ability to operate in high, low, forward, neutral, and reverse modes.
The transmission features an all-wheel-drive architecture with an electrically engaging front axle: 2x4 and 4x4 modes allow for quick adaptation to road conditions. The presence of two locked differentials enhances off-road capability on difficult terrain, and the final drive is direct. For precise speed control, hydraulic disc brakes with three discs and reinforced brake hoses are installed.
The steering system is equipped with a three-mode electric power steering (EPS) — standard, maximum, and off modes allow for comfortable steering in any riding conditions, reducing driver fatigue. The lighting is fully LED with matrix technology, ensuring bright illumination and high efficiency.
Body and chassis: the plastic bodywork is made of high-strength ABS plastic (front bumper, side mudguards, fender flares), while the metal bodywork is a tubular structure integrated into the frame, allowing for the installation of additional storage boxes. There is a removable radiator grille for easy maintenance. The included tow hitch and winch enhance functionality for work and towing. Alloy wheels and quality finishing of external elements emphasize the practicality and appearance of the model.
Dimensions and performance — the Blade 550 EPS has dimensions of 2200x1250x1300 mm and a wheelbase of 1300 mm, providing an optimal combination of maneuverability and stability. The fuel tank capacity is 17 liters, and the dry weight of the model is approximately 320 kg. Tire size: front 25x8-12, rear 25x10-12. Front suspension — independent McPherson with double A-arms, coil springs, and shock absorbers; rear suspension — independent, double A-arms, coil springs, and shock absorbers.
Key advantages of the model:
- Reinforced frame structure and Japanese CVT variator components;
- Removable radiator grille for easy cleaning;
- Electrically engaging 4x4 drive with 2x4 and 4x4 modes;
- Two locked differentials for enhanced off-road capability;
- Three-mode EPS electric power steering;
- Extended chassis with a separate passenger seat in front;
- Included tow hitch and winch for work and towing;
- Alloy wheels and quality exterior finish.
Technical specifications
| Wheel formula | 4x4 |
| Engine power, hp | 39 hp at 6500 rpm. |
| Engine type | gasoline, 4-stroke, fuel-injected |
| Engine displacement, cm3 | 503 |
| Maximum torque, Nm | 46.1 |
| Ignition system | ECU |
| Engine starting system | electric starter |
| Cooling system | liquid |
| Transmission (gearbox) | CVT variator |
| Gearbox modes | high, low, forward, neutral, and reverse / all-wheel drive, 2x4 and 4x4 modes |
| Differential lock | yes |
| Final drive | direct |
| Front brakes | disc |
| Rear brake | disc on wheel axle |
| Wheelbase, mm | 1300 |
| Tire size | front 25x8-12, rear 25x10-12 |
| Fuel tank capacity, L | 17 |
| Dimensions, LxWxH mm | 2200x1250x1300 |
| Front suspension | independent McPherson, double A-arms, coil springs, shock absorbers |
| Rear suspension | independent, double A-arms, coil springs, shock absorbers |
| Weight, kg | 320 |
| Plastic bodywork | high-strength ABS plastic (front bumper, side mudguards, fender flares) |
| Metal bodywork | tubular, integrated into the frame with the possibility of installing additional storage boxes |
By ordering from the "Flash Army" online store, you get the opportunity to buy an ATV without prepayment with delivery throughout Ukraine, paying in cash or by bank transfer. We provide consultations on operation, help with selecting additional equipment and accessories — tow hitch, winch, storage boxes, and more. For availability and delivery conditions, please contact our online store managers.
TGB Blade 550 EPS — a practical solution for Ukrainian riders who need a reliable, versatile, and comfortable ATV for work and leisure.
