EcoFlow Power Kit Control Panel — Smart AC/DC Distribution Panel
Brand: EcoFlow. The EcoFlow Power Kit Control Panel is a modern AC/DC Smart Distribution Panel designed for reliable and convenient management of off-grid power systems in homes, cottages, or campers. The device provides both AC and DC power distribution with control capabilities via a hardware console and the EcoFlow Power Kit mobile app, allowing for remote monitoring and management of loads.
The panel supports connection to up to six AC circuits and up to twelve DC circuits, with six DC circuits individually controllable from the console or via the app. The maximum AC power is 16A at 230V, up to 3600W, and the maximum DC input is 70A, allowing it to handle significant household and professional loads.
Key Features
- Supports simultaneous AC and DC power distribution.
- 6 positions for AC, each up to 10A.
- 12 DC connections, 6 of which are controllable via console or app.
- Maximum AC input: 16A, 230V, 3600W.
- Maximum DC input: 70A.
- Compact dimensions and light weight for easy installation and integration.
- Operating temperature range: -20°C to 60°C.
The panel is compact (net weight 2.6 kg, dimensions 20.3x33x7.6 cm — height x width x depth), making it convenient for installation in confined spaces and integration into existing systems. The enclosure protection level is IIP21. The device has passed the necessary tests and holds safety certificates: UL Standard, FCC, PSE, ensuring compliance with international operating requirements.
Main AC Input | 16A Max. 230V, 3600W |
Main DC Input | 70A Max |
AC Output | 6 AC positions, 10A max each |
DC Output | 12 DC connections (6 positions controllable via console and Power Kit app) |
Net Weight (kg) | 2.6 |
Size (cm) | 20.3x33x7.6 (height x width x depth) |
Protection Level | IIP21 |
Tests and Certificates | UL Standard, FCC, PSE |
Storage Temperature (C) | -20°C to 60°C |
Operating Temperature (C) | -20°C to 60°C |
The panel is designed for users who value control over energy consumption, safety, and flexible settings. It is ideal for organizing centralized energy control in off-grid systems, campers, cottages, or as an additional module in a home power grid. Control via the hardware console and mobile app allows for setting load priorities, remotely switching individual circuits on or off, and tracking current energy consumption.
Please note: the manufacturer reserves the right to change the composition, configuration, color scheme of the product, warranty period, technical specifications, and other details without prior notice. Product description, technical specifications, and configuration may vary.
Category: Energy Independence > Accessories. This model is suitable for those seeking a compact and reliable solution for centralized energy consumption control with remote management via an app.
