Additional
Corrugated covers for front fork stanchions
Air Filter
Disposable paper
Anti-theft alarm
None
Balancing shaft
None
Battery type, capacity, A*h
Lead-acid, 5
Brake Fluid
None
Camshaft position
Top
Clutch
Mechanical, multi-disc, oil-bath
Cooling type
Air cooling
Cylinder diameter, piston stroke, mm
53
Dashboard
Separate. Mechanical speedometer and tachometer, indicators: gear number, high beam, turn signals
Driver Footpegs
Platform type with anti-slip pad
Driver's seat height, mm
780
Engine and transmission crankcase capacity, L
0.5
Engine displacement, cm3
107
Engine model
1P52FMI
Engine oil type
Semi-synthetic motor oil, SG, SF class or higher, for 4-stroke motorcycle engines
Engine type
Single-cylinder, four-stroke, carbureted, with overhead valves
Exhaust pipe heat shield
None
Frame
Duplex, tubular frame
Front brake type
Drum mechanical
Front Optics
Round incandescent headlight. Incandescent turn signals
Front Shock Absorbers
Oils
Front wheel disc
Light alloy cast 5-spoke
Front Wheel Suspension
Telescopic Fork
Fuel Delivery System
Siphon
Fuel Filters
Replaceable mesh (paper) on the fuel line
Fuel tank capacity, L
8.0
Fuel type
Gasoline with an octane rating of at least 92
Gearbox
Mechanical 4-speed, rotary (pattern -0-1-2-3-4-)
Generator, (voltage, V) / (power, W)
14/85
Ignition
Electronic, CDI
Ignition lock blocking
None
Maximum crankshaft speed, RPM
7000
Maximum speed, km/h
85
Motorcycle Helmet Case
Quick-release portable
Motorcycle type
Road Light
Nominal fuel consumption, L/100 km
2.0
Number and placement of valves
2, top
Number of slots
Two-person
Oil Filter
Polymer Net
On-board power supply voltage, V
12
Overall dimensions (LxWxH), mm
1900x650x1150
Passenger Footpegs
None
Passenger leg protection
None
Payload capacity, kg
150
Rated power, kW (hp)
5.2 / 7.0
Rear Brake Type
Drum mechanical
Rear Optics
Rear combination lamp, surface-mounted: brake, tail, license plate illumination (incandescent bulbs). Turn signals with incandescent bulbs
Rear Rack
Full-size
Rear Shock Absorbers
Spring-oil
Rear Wheel Disc
Light alloy cast 5-spoke
Rear wheel drive
Chain drive 14/40 in protective housing
Rear Wheel Suspension
Pendulum with two shock absorbers
Roll Bars
Painted black
Seat
Road-type, soft, single-level, full-length
Silencer cover
Painted
Starter type
Electric starter, kickstarter
Steering wheel lock
Steering column lock
Structural weight, kg
82
Tire size: front/rear
2.50-17 / 2.75-17
Tool Kit (ZIP)
Standard
Tread pattern, front/rear
Road universal "asphalt/dirt"
Wheelbase, mm
1180
