Mototractor DW 160 WXL — an optimal solution for home farming

The DW 160 WXL mototractor from the manufacturer DW is reliable and affordable equipment for cottages, private farms, and small businesses. Recommended for cultivating plots from 0.06–0.1 hectares up to 1 hectare, it is perfectly suited for plowing, milling, hilling, transporting firewood and building materials, sand, and removing waste. The model belongs to the category: Tractors > Mototractors.

Engine and related systems

The DW 160 WXL is equipped with a single-cylinder, horizontal, four-stroke diesel engine, model 195NL, with condenser-type water cooling. The nominal engine power is 15 hp, displacement is 709 cm3, and nominal speed is 2300 rpm. Starting is possible both with an electric starter and manual start (Z-shaped handle). The fuel supply system uses a high-pressure fuel pump (HPFP), injection pressure is 12753 kPa (130 KMF/cm2), and injection advance angle is 16±2. A sedimenter is used for coarse cleaning. The flywheel rotation direction is counter-clockwise. Lubrication is provided by a gear pump with a splash lubrication system. Cold engine valve clearances: intake 0.25±0.05 mm, exhaust 0.30±0.05 mm. Engine weight is 150 kg.

Chassis, brakes, and hydraulics

The mototractor has rear-wheel drive. The front track is adjustable within 1100–1300 mm, and the rear track within 900–1300 mm. Wheel sizes: front 5.00-12, rear 6.5-16 with a chevron tread pattern. Ground clearance is 250 mm. The braking system consists of two drum brakes on the rear axle.

The single-point (motoblock type) rear hitch has sufficient strength for working with a rotary tiller, single-furrow plow, hiller, and other implements. The maximum hitch lifting capacity is 130 kg. With a tow hitch, the mototractor can pull trailers weighing up to 1000 kg.

Controls, transmission, and operational advantages

Control is classic, steering, without power steering. The dashboard is simple and functional: engine temperature gauge, oil pressure gauge, and battery charge indicator. The clutch is single-disc, dry type, constant action, friction type.

The gearbox is a combined type (3 + 1) * 2 with cylindrical gear drive. Torque transmission from the engine to the chassis and hydraulics is via a belt. Gearbox oil volume is 5 L. The driver's seat is equipped with an adjustable seat (forward-backward), levers for controlling the rear lifting mechanism are located on the right; there are pedals for main and hand throttle, a handbrake, and the main brake.

The low cost of the model is due to the use of simple and proven technical solutions, making the DW 160 WXL an economically advantageous choice for home farming and organizing small-scale production.

Key user benefits

• 1. Reliable vertically mounted 195NL diesel engine with water cooling and electric starter.
• 2. Ease of maintenance and low operating costs due to proven technical solutions.
• 3. Multifunctionality: plowing, milling, hilling, cargo transportation, and working with a trailer up to 1000 kg.
• 4. Adjustable tracks and standard wheel sizes for working on various soils.

Technical specifications:

Moto Kosmos company recommends ordering the DW 160 WXL mototractor for efficient home farming, fulfilling orders, and organizing small-scale production. The equipment quickly pays for itself when used for commercial purposes: growing vegetables, fruits, and other products for sale. To purchase, leave an application on the website or call the sales department. Shipment after order confirmation.
