Mototractor DW 160 SXL — a compact work unit from DW
The DW 160 SXL mototractor from the DW brand is an affordable and well-designed piece of equipment for small farms, utility services, and private use. The DW 160 SXL model combines economical fuel consumption, a robust frame design, and an updated hood and fender design. This mototractor belongs to the category: Tractors > Mototractors and offers an optimal balance of price and quality for performing a wide range of tasks.
Advantages and Features
The DW 160 SXL has several practical advantages that make it an attractive choice:
- competitive cost with a reliable technical base and factory assembly;
- updated proprietary design with a rounded hood, integrated radiator grille, and headlights;
- driver ergonomics: adjustable seat and convenient placement of control levers;
- built-in generator for full battery charging and stable power supply to peripherals;
- three-point hitch with floating mode for working with various attachments;
- full set of lighting equipment: front and rear headlights, turn signals, and warning lights.
Technical Features and Operation
The mototractor is equipped with a single-cylinder 15 hp diesel engine with a liquid cooling system, ensuring stable operation and protection against overheating. Control is facilitated by a combined 8-speed gearbox (combined type (3 + 1) * 2) and a two-disc clutch — gear shifting is smooth and precise. The presence of a rear-wheel differential lock minimizes slippage on difficult terrain, and the classic steering mechanism makes control intuitive.
The wheel formula and tread provide good grip: front wheels 5.00-12, rear wheels 6.5-16 with a chevron pattern. The track width of the front wheels (1100, 1200, 1300 mm) and rear wheels (900-1300 mm) can be adjusted for specific crops and working conditions. The structural weight of 470 kg and ground clearance of 250 mm allow working on areas with varying terrain.
Where to Buy and Delivery
You can order the DW 160 SXL mototractor in the online store with prompt order processing. Delivery is carried out throughout Ukraine, including Kyiv and other regional centers. Store managers will help with the selection of attachments, delivery arrangements, and operational consultation.
Specifications:
Engine | JD-16 |
Type: | Horizontally positioned diesel four-stroke engine 195NL with water cooling |
Starting method: | Electric starter + manual start (Z-shaped handle) |
Engine displacement: | 709 cm3; |
Rated power: | 15 hp |
Rated speed: | 2300 rpm |
Cooling system: | condenser |
Flywheel rotation direction: | counter-clockwise |
Lubrication: | gear pump with splash lubrication system |
Injection pressure: | 12753 kPa (130 KMF / cm 2;) |
Fuel injection advance angle: | 16±2 |
Intake valve clearance (cold engine): | 0.25±0.05 mm |
Exhaust valve clearance (cold engine): | 0.30±0.05 mm |
Engine weight: | 150 kg |
Overall dimensions without attachments, mm: | 2200x1100x1770 |
Ground clearance: | 250 mm |
Structural weight of mototractor: | 470 kg |
Rear wheels: | 6.5 -16, chevron tread pattern |
Front wheels: | 5.00 -12 |
Tire pressure, field conditions: | 80 ~ 120 (0.8 ~ 1.2 kg force / cm2;) |
Tire pressure, transport: | 140 ~ 200 (1.40 ~ 2.00 kg force / cm2;) |
Front wheel track, mm: | 1100,1200,1300 |
| Rear wheel track, mm: | 900-1300 |
Rated trailer load weight: | 1000 kg |
Clutch: | single-disc, dry type, with constant engagement, friction type |
Gearbox: | combined type (3 + 1) * 2, with cylindrical gear drive |
Speed, 1st gear forward: | 2.24 km / h |
Speed, 2nd gear forward: | 3.48 km / h |
Speed, 3rd gear forward: | 5.62 km / h |
Speed, 4th gear forward: | 9.10 km / h |
Speed, 5th gear forward: | 14.10 km / h |
Speed, 6th gear forward: | 22.78 km / h |
Speed, 1st gear reverse: | 1.72 km / h |
Speed, 2nd gear reverse: | 6.97 km / h |
Final drive: | single-stage, spur cylindrical gear drive |
Steering mechanism: | classic steering wheel |
Brake: | 2 drum brakes |
Gearbox oil volume (L): | 5 |
The DW 160 SXL performs a wide range of tasks: plowing and soil preparation, bed formation, mowing, cargo transportation (rated trailer weight up to 1000 kg), and other agricultural or utility tasks thanks to its versatile attachments. Information on technical parameters will help you choose the optimal configuration for your farm. If you need help choosing attachments or arranging delivery, please contact the store managers.
