Technical Specifications

General Information

Number of Screens: 1
Screen Size Class: 27" (68.58 cm)
Viewable Screen Size: 27" (68.58 cm)
Screen Mode: Full HD

Panel and Image

Panel Technology: In-plane Switching (IPS) Technology
Response Time:

• 5 ms GTG (Fast)
• 8 ms GTG

Aspect Ratio: 16:9
Pixel Pitch: 0.3114 mm × 0.3114 mm
Horizontal Viewing Angle: 178°
Vertical Viewing Angle: 178°
Maximum Resolution: 1920 × 1080
Standard Refresh Rate: 100 Hz
Color Support: 16.7 Million Colors
Static Contrast Ratio: 1,000:1
Brightness: 250 cd/m²
Color Gamut: 72% NTSC (CIE 1931)
Pixel Density (PPI): 81

Scan Frequencies

Horizontal Frequency:

• 30–83 kHz (VGA)

Vertical Frequency:

• 48–100 Hz (HDMI 1.4)
• 56–76 Hz (VGA)

Ergonomics

Tilt Angle: -5° / +21°
Adjustments:

• Tilt
  Stand: Included
  Mounting: VESA 100 × 100 mm
  Glass Hardness: 3H
  Mount Type: Panel Mount

Interfaces

• 1 × HDMI (HDCP 1.4, up to 1920×1080 @ 100 Hz)
• 1 × VGA

Power

Input Voltage: 100–240 V AC
Consumption:

• Operating Mode: 16.30 W
• Standby Mode: 0.3 W
• Off Mode: 0.3 W
• Maximum Consumption: 28 W
  Current: 1.50 A
  Frequency: 50 / 60 Hz
  Energy Efficiency Class: ENERGY STAR 8.0

Physical Parameters

Dimensions without Stand: 361.86 × 611.10 × 49.22 mm
Dimensions with Stand: 453.71 × 611.10 × 199.87 mm
Weight: 3.56 kg
Weight with Stand: 4.40 kg

Bezels:

• Top: 6.60 mm
• Bottom: 13.37 mm
• Left: 6.61 mm
• Right: 6.61 mm

Operating Conditions

Temperature:

• Operating: 0°C – 40°C
• Non-operating: -20°C – 60°C

Humidity:

• 10% – 80% (non-condensing)
• 5% – 90% (non-operating)

Maximum Altitude:

• Operating: 4998.72 m
• Non-operating: 12192 m

Package Contents

• Monitor
• Stand
• QR Code
• Safety Instructions
• Power Cable
• HDMI Cable (1.8 m)

Additional Information

Country of Origin: China / Thailand
Environmental Standards: RoHS, ErP Lot 5
Certification: ENERGY STAR 8.0
