Monitor Technical Specifications

General Characteristics

• Diagonal: 23.8"
• Active Area (H × V): 527.04 × 296.46 mm (20.75" × 11.67")
• Screen Area: 156,246.28 mm² (242.18 in²)
• Panel Type: IPS (In-Plane Switching)
• Maximum Resolution: 1920 × 1080 (Full HD)
• Refresh Rate: 100 Hz
• Aspect Ratio: 16:9
• Pixel Pitch: 0.2745 × 0.2745 mm
• Pixel Density: 92.53 PPI

Image Quality

• Brightness: 250 cd/m² (typical)
• Contrast Ratio: 1500:1 (typical)
• Color Support: up to 16.7 million colors
• Color Gamut: 99% sRGB
• TÜV Eye Comfort: 4-Star
• Flicker Free: Yes

Response Time

• 5 ms (Gray-to-Gray, fast mode)
• 8 ms (Gray-to-Gray, normal mode)

Viewing Angles

• 178° vertical / 178° horizontal

Backlight and Coating

• Backlight Type: LED edgelight system
• Coating: Anti-glare, 3H hardness

Interfaces and Connectivity

• 1× HDMI 1.4 (HDCP 1.4, up to FHD 100 Hz)
• 1× DisplayPort 1.4 (HDCP 1.4)
• 1× DisplayPort-out 1.4 (MST)
• 1× RJ45 Ethernet
• 1× USB-C 3.2 Gen1 upstream (DisplayPort 1.4 Alt Mode, up to 90W PD)
• 3× USB 3.2 Gen1 Type-A downstream
• 1× USB-C 3.2 Gen1 downstream (up to 15W, data only)

Power and Consumption

• Input Voltage: 100–240 V AC (50/60 Hz ±3 Hz)
• Current: 2 A (typical)
• Consumption:
  • Off: 0.3 W
  • Standby: 0.3 W
  • Network standby: 1.0 W
  • Operating: 13.9 W
  • Maximum: 180 W
  • POn: 15.2 W
  • TEC: 49.8 kWh

Ergonomics

• Adjustments: Height, Tilt, Swivel, Pivot
• Height: up to 150 mm (5.9")
• Tilt: -5° / +21°
• Swivel: ±45°
• Pivot: ±90°
• VESA: 100 × 100 mm

Additional Features

• Daisy Chain Support: Yes
• Dell Power Button Sync (via USB-C upstream)
• Dell Display Manager (Easy Arrange)
• Remote Asset Management
• Kensington Security Slot

Audio

• Audio Output: Optional soundbar (sold separately)

Operating Conditions

• Temperature:
  • Operating: 0°C – 40°C
  • Storage: -20°C – 60°C
• Humidity:
  • Operating: 10% – 80% (non-condensing)
  • Storage: 5% – 90% (non-condensing)
• Altitude:
  • Operating: up to 5,000 m
  • Storage: up to 12,192 m

Energy Efficiency and Standards

• ENERGY STAR: Certified
• EPEAT Gold
• EPEAT Climate+
• TCO Certified Displays / Edge
• RoHS: Compliant
• BFR/PVC free (excluding external cables)
• Arsenic-free and Mercury-free (panel)

Mounting

• VESA: 100 × 100 mm

Package Contents

• Monitor
• Stand (base + riser)
• Cable tie
• Quick setup guide
• Safety and regulatory information

Cables

• 1× power cable
• 1× DisplayPort–DisplayPort (1.8 m)
• 1× USB-C – USB-C Gen2 (1.0 m)

Physical Characteristics

• Height with stand: 364.00 – 496.53 mm
• Width with stand: 538.64 mm
• Depth with stand: 181.75 mm
• Height without stand: 314.23 mm
• Width without stand: 538.64 mm
• Depth without stand: 50.03 mm
• Panel weight (VESA): 3.69 kg
• Weight with packaging: 7.24 kg
