Technical Information

• Number of Screens: 1
• Screen Size Class: 22"
• Viewable Screen Size: 21.5"
• Screen Mode: Full HD
• Panel Technology: VA (Vertical Alignment)
• Response Time: 5 ms
  • Details: 5 ms (GTG Fast), 8 ms (GTG)
• Aspect Ratio: 16:9
• Pixel Pitch: 0.2493 x 0.2410 mm
• Viewing Angles:
  • Horizontal: 178°
  • Vertical: 178°
• Mount Type: Panel Mount
• Backlight: LED EdgeLight
• HDCP Support: Yes
• Tilt Angle: -5° to 21°

Features

• BFR and PVC Free
• Arsenic-Free Glass
• Mercury Free
• Anti-glare Coating
• Eye Comfort Technologies
• Security Lock Slot (Kensington)
• Stand Adjustments: Tilt
• Stand Included: Yes
• Glass Hardness: 3H

Video

• Maximum Resolution: 1920 × 1080
• Refresh Rate: 100 Hz
• Color Support: 16.7 Million Colors
• Contrast Ratio: 3000:1
• Brightness: 250 cd/m²
• Color Gamut: 72% NTSC (CIE 1931)
• Maximum Preset: 1920 × 1080 @ 100 Hz
• Pixel Density (PPI): 103

Interfaces and Ports

• 1 × HDMI (HDCP 1.4, up to 1920×1080 @ 100 Hz)
• 1 × DisplayPort 1.2 (HDCP 1.4, up to 1920×1080 @ 100 Hz)
• 1 × VGA

Operating Conditions

• Operating Temperature: 0°C – 40°C
• Storage Temperature: -20°C – 60°C
• Operating Humidity: 10% – 80% (non-condensing)
• Storage Humidity: 5% – 90% (non-condensing)
• Max. Operating Altitude: 5000 m
• Max. Storage Altitude: 12192 m

Power

• Voltage: 100–240 V AC
• Operating Consumption: 11.9 W
• Maximum Consumption: 25 W
• Standby Consumption: 0.3 W
• Off State: 0.3 W
• Frequency: 50/60 Hz
• Current: 700 mA

Physical Characteristics

• VESA Compatible: Yes
• VESA Standard: 100 × 100 mm

Without Stand:

• Height: 28.85 cm
• Width: 49.17 cm
• Depth: 5.03 cm
• Weight: 2.29 kg

With Stand:

• Height: 37.69 cm
• Width: 49.17 cm
• Depth: 17.09 cm
• Weight: 2.92 kg

Bezels:

• Top/Left/Right: 0.66 cm
• Bottom: 1.73 cm

Stand:

• Height: 17.4 cm
• Width: 22.2 cm
• Depth: 19.6 cm

Package Contents

• Pro 22 Monitor
• Stand
• Quick Start Guide
• Safety Information
• Power Cable
• DisplayPort–DisplayPort Cable (1.8 m)

Certifications and Ecology

• ENERGY STAR 8.0
• TCO Certified
• EPEAT Gold / Climate+
• TCO Certified Edge
• RoHS Compliance
• Energy Efficient Product
• Environmentally Safe
