Features:
Backrest section position adjustment function - the patient can be in a sitting or semi-reclining position and perform activities related to normal daily life, which facilitates the patient care process for medical staff and ensures patient comfort.
Leg and intermediate sections position adjustment function - lifting the leg section above the bed level; provides relaxation for the patient's legs, improves blood circulation in the legs, prevents varicose veins, and facilitates the daily leg care process.
Trendelenburg / reverse Trendelenburg position adjustment function - expands the functional properties of the bed in patient treatment.
Bed height adjustment function - ensures convenient patient ingress/egress from the bed and comfort for doctors and nursing staff.
Simultaneous back and leg section position change function - allows for quick adjustment to a comfortable position for the patient.
Cardiopulmonary resuscitation (CPR) function - allows the bed to be quickly leveled to a flat (zero) position and lowered to its lowest height to provide the correct flat surface necessary for initiating cardiopulmonary resuscitation and, if necessary, patient intubation.
Bed mobility - the bed is equipped with four large-diameter swivel casters.
Central braking system - allows the bed to be quickly locked in a stationary position or unlocked for movement with a single pedal press.
Side rails - the bed is equipped with four side rails made of durable ABS plastic resistant to aging and fading. The side rails fold smoothly, facilitating access to the patient from any side.
End rails - quick-release, meeting the needs of emergency clinical care. Made of durable ABS plastic resistant to aging and fading.
IV pole - made of stainless steel with height adjustment function. Can be installed on both sides of the bed.
Bed mattress - 80 mm thick, two-component (coconut fiber and polyurethane foam).
| Parameter | Value |
| Control | Via remote control |
| Drive type | Electric |
| Number of bed sections, pcs. | 4 |
| Overall bed dimensions (LxW) | 2150 x 900 mm |
| Bed height adjustment range from floor | 500 - 670 mm |
| Bed surface dimensions (LxW) | 1940 x 900 mm |
| Overall mattress dimensions (LxWxH) | 1990 x 900 x 80 mm |
| Backrest section tilt range | 0 to 80 ° |
| Intermediate (knee) section tilt range | 0 to 35 ° |
| Bed surface tilt range in Trendelenburg position | 0 to 15 ° |
| Bed surface tilt range in reverse Trendelenburg position | 0 to 15 ° |
| IV pole height adjustment range | 850 to 1600 mm |
| Wheel diameter | 125 mm |
| Net weight | 92 kg |
| Gross weight | 110 kg |
| Maximum safe load | 250 kg |
| Power supply parameters | 220 V +-10% , 50 Hz +-2 Hz |
| Power consumption | 105 W |
