Electric Winch 6.35 t 24V Husar Winch BST S 14000LBS
The Husar Winch BST S 14000LBS is a powerful and reliable solution for heavy-duty tasks: vehicle recovery, off-road operations, special equipment, and trailer mounting. The model is designed for a 24V electric motor and has a nominal pulling force of 6.35 tons (14000LBS / 6350kg), allowing it to easily handle intense loads.
Key features: a three-stage planetary gear system ensures smooth and efficient operation; an integrated automatic braking system (dynamic brake) prevents unintentional load slippage; it comes with a 30m cable with a diameter of 10.2 mm and 4-way roller fairleads for even winding.
This model is delivered and installed by certified specialists: we offer installation at our service station or directly at the customer's site. Proper installation is crucial for safe operation. The estimated time for work, including bracket fabrication, is about 8 hours; the exact duration depends on the winch type and mounting location. More detailed information on installation and winch connection can be found on our website or by contacting our manager.
Product category: Tractors, Motorcycles, ATVs, Boats (Vehicle) > Hydraulic Systems > Winches. Brand: Husar (Husar Winch) — a renowned Polish manufacturer whose products are certified and come with an official warranty.
| BST S 14000LBS | Technical Specifications | |||
| Pulling Force | 14000LBS / 6350kg | |||
| Motor 24V | 6.4 hp 4.8kW / 6.7 hp / 5.1kW | |||
| Control | wired / remote control | |||
| Gear System | 3-stage planetary | |||
| Gear Ratio | 332:1 | |||
| Brake | dynamic | |||
| Cable | 30m x 10.2 mm | |||
| Fairleads | 4-way roller fairleads | |||
| Weight | 58kg | |||
| Mounting Bolt Pattern | 254mm x 114.3mm 4-M12 | |||
| Overall Dimensions | (WxDxH) 593mm 226mm 294mm | |||
| Cable Winding Speed and Current Consumption (1st cable layer) | |||||
| Load | LBS | 0 | 8000 | 1000 | 1400 |
| Load | kg | 0 | 3629 | 4536 | 6350 |
| Winding Speed | m/min 24V | 5.4 | 2 | 1.8 | 1.5 |
| Current Consumption | amps 24V | 40 | 145 | 185 | 250 |
| Pulling Force by Cable Layer | |||||
| Cable Layer | 1 | 2 | 3 | 4 | |
| Load | LBS | 14000 | 11255 | 9410 | 8085 |
| Load | kg | 6350 | 5105 | 4268 | 3667 |
| Remaining Cable on Drum | M | 5.6 | 12.5 | 20 | 28.5 |
Husar Winch is a leading brand from Poland, offering a wide range of electric, hydraulic, manual, chain, and industrial winches, as well as accessories: compressors, pulleys, shackles, cables, and other components. The brand's products are in demand across Europe and Asia due to their high quality and reliability.
This model is ideal for SUV owners, recovery workshops, and businesses that require a powerful and durable winch with reliable brakes and precise cable winding control. If you need advice on selection or installation, our specialists will help you choose the optimal option and provide professional service.
