Built-in energy-efficient circulation pump Taso ES2 C 15-70-130
Frost and overheat protection
Heat output: 35.64 kW
Total max. consumption: 36.2 kW
Efficiency: 99.7%
Coil arrangement: 2x12 kW + 2x6 kW
Number of stages: 4(3)
Number of contactors: 4
Output power adjustment: 18 kW - 24 kW - 30 kW - 36 kW
Current: 53 A
Automatic circuit breaker for boiler circuit: 60 A
Min. cross-sectional area of power cables: 5(4)x16 mm2
Boiler fuse type: 160 A
Voltage: 3x400/230 V
Enclosure protection rating: IP40
Terminals for thermostat on/off: 230 V
Max. operating pressure: 2.5 bar
Min. operating pressure: 0.8 bar
Water volume: 29.5 L
Max. water heating temperature: 90°C
Expansion tank not included
Safety valve 1/2": 2.5 bar
Inlet pipe diameter (external thread): G1"
Outlet pipe diameter (external thread): G1"
Boiler weight without water: 53 kg
Device dimensions: 615x870x335 mm
Country of origin: Czech Republic
