Product Code: FA99-VIGI-C340-4-99
3 299 грн.
Buy this product in 1 click:
Main specifications
Warranty:
36 months
Weight (kg):
0.54
All specifications
We will deliver this product:
Payment
Description
- 4MP Super-High Definition: The camera comes with 4MP—more than enough pixels to pick up some of the more discrete details.
- 24h Full-Color: Obtain 24-hour color details even in pitch-black conditions with its large-aperture lens, high-sensitivity sensor, and attached supplemental lights.
- Human & Vehicle Classification: Distinguishes humans and vehicles from other objects, so you receive more accurate event notifications.
- Smart Detection: Receive notifications and check feeds when someone crosses a boundary, enters an area you've set, obstructs the camera, or removes/abandons objects.
- Active Defense: Warn potential intruders instantly with sound and light upon abnormal events.
- Two-Way Audio: Intelligent actions detection, instant informing, and automated responses with smart detection and two-way audio.
- H.265+: Without using any extra bandwidth, your cameras transmit compressed crystal-clear video to save disk space, ease network loads, and reduce monitoring costs without sacrificing image quality.
- Smart Video Enhancement: VIGI professional technologies process videos to greatly improve their quality that is vital for your monitoring, including Smart IR, WDR, 3D DNR, and Night Vision.
- IP67 Waterproof: Reliable IP67 for stable outdoor performance.
- PoE/12V DC: Two types of power supply not only give you more convenience but also make wiring remarkably easy.
- Flexible Management and Storage: Take full control over your security via four management methods: web UI, NVR UI, VIGI App, and VIGI Security Manager. Local storage is available for each method, as well as onboard storage with SD card slot (up to 256 GB).
| CAMERA | |||
|---|---|---|---|
| Image Sensor | 1/3” Progressive Scan CMOS | ||
| Lens | Fixed focal lens (2.8 mm / 4 mm / 6 mm) | Aperture | 2.8mm: F1.6 4mm: F1.6 6mm: F1.6 |
| Lens Mount | M12 | ||
| Viewing Angle | (2.8mm) Horizontal FOV: 102°, Vertical FOV: 55°, Diagonal FOV: 122° (4mm) Horizontal FOV: 79°, Vertical FOV: 43°, Diagonal FOV: 93° (6mm) Horizontal FOV: 50°, Vertical FOV: 27°, Diagonal FOV: 59° | ||
| Day/Night Mode | IR Cut Filter | ||
| IR Working Distance | 30m | ||
| Minimum Illumination | 0 Lux with IR/White Light | ||
| Weatherproof Rating | IP67 | ||
| Digital Noise Reduction | 3D DNR | ||
| WDR | DWDR | ||
| NETWORK | |
|---|---|
| Security | Password Protection, HTTPS Encryption, IP Address Filter, Digest Authentication |
| Protocol | TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS |
| Network Storage | NAS (NFS, SMB/ CIFS) |
| API | Open Network Video Interface (Profile S) |
| Simultaneous Live View | Up to 6 Channels |
| Client | VIGI App, VIGI Security Manager, VIGI NVR, Web |
| Web Browser | Google Chrome® 57 and above Firefox® 52 and above Safari® 11 and above Microsoft® Edge 91 and above |
| Cloud | Yes |
| ONVIF | Yes |
| GENERAL | |
|---|---|
| Package Contents | VIGI Network Camera Quick Start Guide Waterproof Cable Attachments Mounting Accessories |
| Operating Temperature | -30–60 °C |
| Dimensions (W x D x H) | 78 × 70 × 174 mm |
| Certifications | CE, RCM, BSMI, VCCI, RoHS, NTRA, KC |
| Material | Plastic |
| Weight | 195 g |
| General Features | Dual Streams, Mirror, Privacy Masks, Password Reset via E-mail, HTTP Listening |
| Power Supply | 12V DC ± 5%, 5.5mm Coaxial Power Plug PoE (802.3af/at, class 0) |
| Power Consumption | 12V DC: Max 7.5W PoE: Class 0 |
| ILLUMINATOR | |
|---|---|
| IR LED | Quantity: 2 Range: 30m Wavelength: 850nm |
| White LED | Quantity: 2 Range: 30m |
| VIDEO / IMAGE | |
|---|---|
| Video Compression | Main Stream: H.265+/H.265/H.264+//H.264 Sub-Stream: H.265/H.264 |
| H.264 Type | Main Profile/High Profile |
| H.264+ | Main Stream Supported |
| H.265 Type | Main Profile |
| H.265+ | Main Stream Supported |
| Frame Rate & Resolutions | Main Stream: Frame Rate: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps Resolution: 2560x1440, 2304x1296, 2048x1280, 1920x1080, 1280x720 Sub-Stream: Frame Rate: 1fps, 5fps, 10fps, 15fps, 20fps, 25fps, 30fps Resolution: 640x480, 352x288, 320x240 |
| Max. Resolution | 2560 X 1440 |
| Video Streaming | Main Stream Sub-Stream |
| Image Settings | Mirror, Brightness, Contrast, Saturation, Sharpness, Exposure, WDR, White Balance, Prevent Overexposure to IR Light, HLC Adjustable by Client Software, Rotate (90°/270°) |
| Image Enhancement | BLC/3D DNR/HLC/SmartIR |
| Video Bit Rate | Main Stream: 256 Kbps to 4 Mbps Sub-Stream: 64 Kbps to 512 Kbps |
| Day/Night Switch | Day/Night/Auto/Schedule |
| Privacy Mask | Up to 4 Masks |
| SMART FEATURE-SET | |
|---|---|
| Smart Event | Human & Vehicle Classification, Area Intrusion Detection, Line-Crossing Detection, Human Detection, Vehicle Detection, Region Entrance Detection, Region Exiting Detection, Abandoned Object Detection, Object Removal Detection |
| Basic Event | Motion Detection, Camera Tampering Detection, Exception (Illegal Login) |
| Linkage Method | N/A |
| Alarm Linkage | Record Video to Storage Card, Send Notification, Audible Warning, White Light Flashing |
| Output Notification | Push Notification |
| INTERFACES | |
|---|---|
| Network Interface | 1 RJ45 10/100M Self-Adaptive Ethernet Port, PoE |
| Audio Output | N/A |
| Alarm | N/A |
| Button | Reset Button |
| On-board Storage | Built-in memory card slot, support MicroSD card, up to 256 GB |
| Built-in Microphone | Yes |
| Built-in Speaker | Yes |
