Product Code: FA94-31488-94
18 612 грн.
Buy this product in 1 click:
Main specifications
Built-in Interfaces:
RS485/CAN/USB/ Dry contact
Charge current from mains, A:
80
Charge current from panels, A:
80
Height, mm:
103
Input voltage range, V:
UPS: 170-280; APL: 90-280
All specifications
We will deliver this product:
Payment
Specifications
Built-in Interfaces
RS485/CAN/USB/ Dry contact
Charge current from mains, A
80
Charge current from panels, A
80
Height, mm
103
Input voltage range, V
UPS: 170-280; APL: 90-280
Input Voltage Waveform
pure sine wave
Length, mm
378
Max input voltage from panels, V
500
Maximum input current of MPPT controller (DC), A
13
Maximum panel power, W
4000
MPPT voltage range, V
120-450
Nominal Charge Current (AC+PV), A
80
Number of MPPT trackers, pcs
1
Number of Phases
1
Operating temperature, °C
-10 ~ +55
Output frequency range, Hz
50/60
Output voltage, V
230
Power, W
3500
Switching time, ms
10
Type
hybrid
Warranty, months
24
Weight, kg
7.4
Width, mm
280
Color
white
