Product Code: FA94-20086-94
161 595 грн.
Buy this product in 1 click:
Main specifications
Battery connection type to UPS:
Terminals
Charge current from mains, A:
60, 5-300 Adjustable
Efficiency, %:
91
Frequency range, Hz:
50/60
Height, mm:
820
All specifications
We will deliver this product:
Payment
Specifications
Battery connection type to UPS
Terminals
Charge current from mains, A
60, 5-300 Adjustable
Efficiency, %
91
Frequency range, Hz
50/60
Height, mm
820
Input voltage range, V
400-800
Input Voltage Waveform
pure sine wave
Length, mm
219
Max MPPT Voltage (DC), V
900
Maximum input current of MPPT controller (DC), A
2x18.6
Maximum panel power, W
22500
MPPT voltage range, V
400-800
Network Connection Type
Terminals
Nominal battery voltage, V
48
Nominal Charge Current (AC+PV), A
21.7
Nominal input voltage (AC), V
230
Number of MPPT trackers, pcs
2
Number of Outputs
3
Number of Phases
3
Operating temperature, °C
-10 ~ +55
Output voltage waveform
pure sine wave
Output voltage, V
230/400
Panel connection type to UPS
Terminals
PC connection interface
RS-232, USB and Dry contact, Wi-fi
Power, VA/W
15000/15000
Power, W
15000
Type
hybrid MPPT with pure sine wave
Type of UPS load connection
Terminals
Warranty, months
24
Weight, kg
62
Width, mm
650
