An ideal solution for charging batteries in 24V power systems, such as solar power stations, video surveillance systems, security systems, for maintaining/charging batteries while vehicles are parked. Automatic generator operation: in "Auto" mode, the generator functions as a battery charger — when the battery discharges, it automatically starts and recharges it; after charging, the generator stops and goes into standby mode. Operation in MANUAL/EXTERNAL mode: in this mode, you can start the generator manually or using an external device via "dry contacts". Noise-protective casing – significantly reduces noise levels during operation, making the generator comfortable for use in residential or work areas. Indication system – allows for quick monitoring of generator status, oil level, load, and other important parameters.
Voltage, V 24-27
Rated power, kW 1.6
Max current, A 60
Fuel tank capacity, L 5
LED display voltage, amperage
Noise level, LpA (7m)/LwA, dB 62/87
Engine model KS 100i
Engine type gasoline 4-stroke
Engine power, hp 2.5
Oil sump capacity, L 0.4
Engine displacement, cm3 79.7
Start type automatic, manual
Protection class IP23M
Net dimensions, mm 500×285×460
Gross dimensions, mm 625×335×540
Net weight, kg 21
Gross weight, kg 23.0
