Freedom-10 FPV Kamikaze Drone by WINGED LIBERTY FACTORY

Introducing the powerful and reliable Freedom-10 FPV kamikaze drone from WINGED LIBERTY FACTORY. This model combines a 10-inch carbon frame, modern components, and a design capable of carrying a payload of up to 4 kg, making it suitable for various tactical and technical tasks. The product belongs to the categories: Drones and Quadcopters > Kamikaze Drones and also falls under the product type: Drones and Quadcopters > FPV Drones.

Features

• 1. Payload capacity of up to 4 kg allows for carrying additional equipment and payloads for specialized tasks.
• 2. Established serial production with components sourced directly from factories avoids additional brand costs and ensures high-quality components.
• 3. Video transmitter: Diatone Mamba Ultra 5.8G 2.5W (VTX 2500 mW) — a powerful VTX for stable and reliable long-range video communication.
• 4. Recommended batteries: 6s2p 8400mAh or 6s3p 12600mAh for high efficiency and extended flight time.
• 5. The use of an F722 flight controller (STM32F722 series) and a 100A ESC with increased power guarantees stable motor operation and rapid control system response.

Specification

• Model: Freedom-10
• Frame: WLF X10 carbon 10 inch
• VTX: Diatone Mamba Ultra 2500 mW 5.8 GHz
• Camera: WLF MD2 1200TVL 16:9 0.001Lux
• Antenna: WLF 5.8G RHCP RP-SMA 120 mm, VSWR: ≤1.4
• Motors: WLF 3115 900kv x4
• Propellers: WLF 1050, 3 blades, fiberglass-nylon
• Firmware: Betaflight
• FC: WLF F7 L3
• MCU: STM32F722
• Gyroscope: ICM42688
• OSD: AT7456E
• Black box: built-in 8GB SD card
• BEC output: 10V/3A, 5V/3A
• Interfaces: 5x UARTs, 4x Softserial, 1x I2C, 4x RGB
• ESC: WLF 100A AM32
• ESC details: 32-bit F4, 120MHz main frequency, up to 128KHz PWM Packet; throttle signal support: Dshot150-1200, Multishot, Oneshot125
• Current sensor: built-in
• Power cord: XT60
• Weight: 878g
• Receiver: PNP / TBS NanoRX / ELRS 915 / ELRS 720-1020MHz
• Recommended battery: 6s2p 8400mAh or 6s3p 12600mAh
• Flight time: 18-46 minutes (depending on battery configuration and payload)

Package Contents

• 1 x "Freedom-10" 6S Analog BNF drone
• 1 x antenna
• 4 x propellers
• 2 x battery straps

The Freedom-10 combines a WLF X10 carbon frame, powerful WLF 3115 900kv motors, and efficient WLF 1050 three-blade propellers for optimal thrust. The integrated electronics package — a WLF F7 L3 flight controller based on STM32F722, a high-precision ICM42688 gyroscope, and an AT7456E OSD — ensures precise control, flight stability, and parameter recording to the built-in 8GB SD card (black box). The WLF 100A AM32 ESC with Dshot support and high-frequency PWM guarantees reliable motor operation even under heavy load. The powerful Diatone Mamba Ultra 2500 mW VTX, in conjunction with the WLF RHCP antenna, provides stable 5.8 GHz video communication.

Recommended 6s2p 8400mAh or 6s3p 12600mAh batteries allow for a flight time of 18-46 minutes depending on the chosen configuration and payload mass. The model easily adapts to various receiver types: PNP, TBS NanoRX, or ELRS (915 / 720-1020MHz), making the Freedom-10 a flexible solution for different tasks and operating conditions.

This FPV kamikaze drone is designed for demanding users who require a combination of high payload capacity, extended flight time, and reliable video communication. Thanks to the serial approach to components and the possibility of customizing electronics and receivers, the Freedom-10 is suitable for both field operations and specialized technical missions.
