Product Code: FA122-165164-122
4 694 грн.
Buy this product in 1 click:
Main specifications
Cooling System: forced air
Cylinder bore / piston stroke, mm: 68 / 54
Engine displacement, cc: 196
Engine oil capacity, L: 0.6
Engine power, hp: 6.0
All specifications
We will deliver this product:
Payment
Description

Description of VitalsGE 6.0-20k Gasoline Engine

The Vitals GE 6.0-20k internal combustion engine is a universal gasoline single-cylinder four-stroke general-purpose engine with air cooling.

The Vitals GE 6.0-20k internal combustion engine, with a power of 6.0 hp and a displacement of 196 cm3, can be used in mini power plants, agricultural machinery: tillers, motor cultivators, mowers, self-propelled chassis, irrigation systems, and construction equipment: vibratory plates, impact rammers, concrete mixers, compressors.

The engine mounting is universal.

The high quality of components, professional assembly, and two-stage air filtration, provided by a foam filter and an oil bath, guarantee a long service life of the engine.

The pulley is fixed on the output shaft of the Vitals GE 6.0-20k engine to transmit torque to various auxiliary units, systems, and components using a key.

A manual starter is used to start the engine. To prevent engine damage, an emergency system is provided in case of no oil in the crankcase or an insufficient amount. Thus, if the oil level in the crankcase is low, the protection system will stop its operation, preventing breakdown. For easier access from different sides of the engine crankcase, two oil filler necks with dipstick plugs are provided.

Thanks to its compact dimensions and light weight, the Vitals GE 6.0-20k engine can be used as a power unit for vehicles, including water transport: boats, motorboats, and small yachts.

The warranty for the Vitals GE 6.0-20k engine is 36 months.

Specifications
Cooling System forced air
Cylinder bore / piston stroke, mm 68 / 54
Engine displacement, cc 196
Engine oil capacity, L 0.6
Engine power, hp 6.0
Engine type 4-stroke single-cylinder
Fuel consumption, g/kW*h 380
Fuel tank capacity, L 3.6
Fuel type gasoline A-92
Internal Thread M8x1.25
Keyway length / width, mm 45.0 / 5.0
Launch System Hand starter
Low engine oil level sensor +
Net / Gross Weight, kg 13.5/14.5
Package dimensions, mm 380×330×350
Paper Air Filter +
Shaft shank diameter, mm 20,0
Shaft shank length, mm 56.0
Shaft shank type keyed with central internal thread
