Product Code: FA94-29455-94
29 739 грн.
Buy this product in 1 click:
Main specifications
Application: uninterruptible power supplies
Battery storage temperature, °C: -20 ~ +40
BMS: 12V 4S Dis 80A Ch 40A
Charge operating temperature, °C: 0 ~ +40
Charging voltage (buffer mode), V: 13.8
All specifications
We will deliver this product:
Payment
Description

New generation LiFePO4 batteries have high efficiency (up to 94%), low self-discharge, and a wide operating temperature range (-15 ~ +60°C).

LiFePO4 batteries charge quickly, are completely sealed (can be operated in any position), and have compact dimensions.

All of the above makes LiFePO4 indispensable for those looking for the best lithium battery for a UPS.

The operating principle of a UPS with an external battery is structured so that when power disappears from the main grid, the battery delivers its stored capacity to the consumer (the battery discharges), and then, after power is restored to the grid, the UPS automatically charges the battery.

Practical application has shown that a universal LiFePO4 battery is not compatible with all types of UPS. Most standard uninterruptible power supplies "do not see" a discharged lithium battery and, as a result, do not charge it.

If you need a battery for a UPS and don't know which is best, choose lithium iron phosphate batteries for your UPS from LogicPower.

LogicPower technical specialists have developed and implemented a unique circuit that allows all modifications of uninterruptible power supplies to charge LiFePO4 batteries without problems.

ATTENTION! The battery is prohibited from being used as a starter battery in cars and other vehicles!

Quality Guarantees and Technical Support

LogicPower batteries for uninterruptible power supplies are manufactured in Ukraine using the technologies of leading global manufacturers of lithium batteries.

We provide a manufacturer's warranty on all types of batteries. Warranty repairs and technical maintenance are carried out in certified service centers.

Rules and Terms of Delivery for UPS Batteries

Battery manufacturing and delivery time is 5-7 days.

Practical advice from a technical expert on how to effectively use a battery during a blackout.

Specifications
Application uninterruptible power supplies
Battery storage temperature, °C -20 ~ +40
BMS 12V 4S Dis 80A Ch 40A
Charge operating temperature, °C 0 ~ +40
Charging voltage (buffer mode), V 13.8
Charging voltage (cyclic mode), V 14.6
Discharge operating temperature, °C -4 ~ +140
Full charge voltage, V 14.6
Height, mm 230
Housing material Plastic
Internal resistance, mOm less than 0.5
Length, mm 405
Maximum charge current, A 40
Maximum discharge current, A 80
Minimum voltage, V 10.5
Nominal capacity, Ah 160
Nominal charging current, A 40
Nominal discharge current, A 80
Nominal values of elements 160
Nominal voltage, V 12 (12.8)
Number of cycles 7000
Number of elements in group S 4
Number of items in group R 1
Peak discharge current (100 ms), A 260
Short-circuit current, A 260
Starting current, A 260
Terminal type M8 copper screw
Type LiFePO4
Warranty, months 60
Weight, kg 15
Width, mm 175
