6s3p Li-ion Batteries - High Power and Efficiency
Today's realities dictate their own rules and demand not only reliability but also energy efficiency and performance from battery packs. 6s3p batteries hold a key position among others that offer such advantages. These batteries are used in various fields. In the description, we will consider the main directions.
6s3p Li-ion Battery - Specifics
In battery packs, the configuration indicates the number of elements connected in parallel and in series. For example, 6s is a series connection, which affects the voltage, and 3p is a parallel connection, which is responsible for capacity and current.
6s3p Li-ion Battery with Lishen Cells - Advantages:
- High voltage is provided by 6 elements with a series connection. The voltage of each element adds up to 21.6 V. This makes 6s3p very well suited for more demanding devices.
- To increase flight duration, a parallel connection is used. Three groups of elements increase the total capacity of the pack and provide 12000 mAh. This allows the device to operate for a long time without recharging.
- With optimal weight, the 6s3p pack will not overload the drone and will power it for a long time, sufficient to complete a combat mission.
- The battery is designed with original Lishen LR2170LA cells. The cells also undergo additional testing at our production facility before being used in the pack. Thanks to this, our product does not contain defective elements that could affect the mission outcome.
Buy Li-ion Batteries Quickly and Without Risks
Only high-quality batteries and packs are sold in the FlashArmy brand store. All of them undergo testing and only then are sent to store shelves or to the end consumer. You can always place an order on the company's website or simply call the toll-free hotline. Our managers will be happy to help you choose a battery for drones, or accept a technical specification for development. All products presented are in stock, so delivery will be arranged as soon as possible. If you still have any doubts, order the pack with cash on delivery to a convenient carrier branch. We do not require any prepayments.
Specifications
| Capacity, mAh | 12 000 |
| Nominal voltage, V | 21.6 |
| Peak discharge current, A | 135 |
| Dimensions (LxWxH), mm | 128x63x72 |
| Weight, kg | 1.21 |
| Country of manufacture | Ukraine |
| Configuration | 6s3p |
| Cell type | Li-Ion |
| Cells | LISHEN LR2170LA |
| Power cable | AWG 10 |
| Power connector | XT-60 |
