Dobrota 4-channel EW Jammer Kit (optional) — a portable, integrated counter-UAV system for copter-type drones from the manufacturer REBy Dobroty, designed for rapid deployment and reliable protection of perimeters, guarded facilities, military positions, and other critical areas from unauthorized FPV drones and small unmanned aerial vehicles.
Design and Package Contents
The portable system consists of a main EW generator with three built-in non-removable antennas (collinear), a wired control panel, a battery, and a charger. This configuration ensures rapid deployment to a position and minimal personnel training requirements. The antennas are omnidirectional with high gain for reliable signal jamming in the designated area.
Application
The kit is suitable for operational units, security services, and other users who require rapid suppression of drone control and video transmission channels. Thanks to its portability, autonomous power supply, and ease of operation, it can be used in field conditions and at stationary guard posts.
Specifications
Technical parameters influencing system selection and operation:
| Antenna type | Collinear |
|---|---|
| Jamming power at jammer output, W | 50 |
| EW jamming frequency ranges | 264 |
| EW jamming frequency ranges | (optional) |
| EW jamming range, m | 150 |
| Power supply voltage, V | 13 |
| Power supply voltage (12/24/220) | 12 V |
| Internal battery operation capability | No |
| Uninterrupted battery operation time, min | 30 |
| Uninterrupted battery operation time | 60 min |
| Product codified | No |
The product is certified according to the internal standards of the manufacturer LLC «REBy Dobroty». Key indicators: 50 W power, effective jamming range up to 150 m, powered by 12 V/13 V (with the possibility of connecting to 12/24/220 V networks depending on configuration). Please note that the specification lists both 13 V and 12 V for separate power options; there are also two values for battery operation time (30 min and 60 min), which may correspond to different modes or battery configurations. The ability to operate from an internal battery is stated as «No», however, the system includes a battery and charger for autonomous operation in field conditions.
Product type: EW Jammers > Trench EW Jammers. Manufacturer: REBy Dobroty. The «Dobrota» kit is distinguished by its ease of transport, simplicity of use and maintenance, making it an optimal solution for rapid deployment of electronic warfare equipment.
