10" Brotherhood Drone Frame — Robust, Lightweight, and Adaptive Design
The drone frame from Brother Hood combines an aluminum alloy for the arms and STEFF-1 fiberglass laminate for the body plates, ensuring an ideal balance of weight, rigidity, and durability. The design is engineered for 10-inch propellers and optimized for FPV and lightweight recreational configurations where maneuverability and reliability are crucial.
Key Advantages
- Composite materials: aluminum alloy for arms and STEFF-1 fiberglass laminate for the body;
- Low weight with high strength — the weight budget is meticulously planned;
- Option for custom modification of mounting holes for motors, cameras, and other components;
- Available configurations: assembled frame or disassembled frame — the kit includes all parts and hardware;
- Optional professional custom body painting (color of choice);
- Supply of complete drones or individual components in any quantity for customer projects.
Technical Specifications
| Parameter | Value |
|---|---|
| Material | Aluminum alloy for arms and STEFF-1 fiberglass laminate |
| Country of Origin | Ukraine |
| Body Color | Yellow |
| Configuration | Assembled frame (disassembled frame also available) |
| Assembled Frame Weight | 360 g |
| Fiberglass Laminate Weight | 138.5 g (also specified as 138 g) |
| Arm Weight | 192 g |
| Size with Arms (mm) | 351x351x44 |
| Size without Arms (mm) | 258x91x34 |
| Distance between Motor Centers (mm) | 319 |
| Motor Mount Size (mm) | 19 |
| Camera Mount Size (mm) | 19 |
| Arm (aluminum profile) (mm), wall (mm) | 10x20x237 / 1.5 |
| Bottom Plate (fiberglass laminate) (mm) | 258x91x3 |
| Top Plate (fiberglass laminate) (mm) | 258x45x3 |
| Camera Bracket (fiberglass laminate) (mm) | 31x26x3 |
| Additional Plate (fiberglass laminate) (mm) | 91x91x3 |
The frame is optimized for 10-inch propellers, making it an ideal solution for fast and agile configurations. It allows for modification of mounting holes for motors and other components, enabling adaptation to individual needs or non-standard motor ramps. The 19 mm mounting dimensions allow for the installation of video cameras and brackets for stable equipment fixation.
The frame is offered in two configuration options: assembled and disassembled — in both cases, the kit includes all necessary elements and hardware. An additional service of body painting is available upon request; other structural modifications can be custom-ordered. We also accept orders for serial production of complete drones or individual components in any quantity. Prices are listed without VAT.
Product Brand: Brother Hood. Category: Drones & Quadcopters > Frames. If you need a frame with an excellent combination of rigidity and low weight, with customization and professional painting options — this model will be a reliable foundation for your project.
